ATEN 4K DP KVM over IP Transmitter W/POE
ATEN 4K DP KVM over IP Transmitter W/POE, Transmitter, Wired, 10000 m, Cat5e, 3840 x 2160 pixels, 36 bit
Availability:: Arriving soon
The KE9952 4K DisplayPort Single Display KVM over IP Extender consists of a high performance IP-based transmitter KE9952T that connects to the computer and receiver KE9952R that provides console access from a separate location. The KE9952 allows access to a computer system from a remote USB console (USB keyboard, USB mouse, DisplayPort monitor) over an intranet, enabling users to locate computers in a secure and temperature controlled environment, which is isolated from users' workstation.1x KE9952T 4K DisplayPort Single Display KVM over IP Transmitter with PoE1x LIN5-20K1-K13G DisplayPort Cable1x LIN6-04U1-V1BG USB 2.0 Type-A to Type-B Cable1x Foot Pad Set (4 pcs.)1x Mounting Kit1x User Instructions
| Features | |
|---|---|
| Type | Transmitter |
| Connectivity technology | Wired |
| Maximum transfer distance | 10000 |
| Cable types supported | Cat5e |
| Rack mounting | Y |
| Maximum digital resolution | 3840 x 2160 |
| Colour depth | 36 |
| Product colour | Black |
| Material | Metal |
| LED indicators | Y |
| Certification | RoHS |
| Transmitter | |
| Transmitter video port type | DisplayPort |
| Number of displays supported | 1 |
| Transmitter local keyboard/mouse port type | USB |
| RJ-45 ports quantity (transmitter) | 1 |
| Ports & interfaces | |
| RS-232 ports | 1 |
| PC Audio in | Y |
| PC Audio out | Y |
| Power | |
| AC adapter output voltage | 48 |
| Power consumption (transmitter) (max) | 11.88 |
| Weight & dimensions | |
| Transmitter width | 215 |
| Transmitter depth | 162.9 |
| Transmitter height | 41.8 |
| Transmitter weight | 1150 |
| Packaging data | |
| Package width | 207 |
| Package depth | 414 |
| Package height | 117 |
| Package weight | 1840 |
| Packaging content | |
| Cables included | DisplayPort,USB |
| Manual | Y |
| Operational conditions | |
| Operating temperature (T-T) | 0 - 50 |
| Storage temperature (T-T) | -20 - 60 |
| Operating relative humidity (H-H) | 0 - 95 |
| Technical details | |
| Weight | 1400 |
| Logistics data | |
| Master (outer) case net weight | 4200 |
| Harmonized System (HS) code | 84733080 |
| Master (outer) case width | 370 |
| Master (outer) case length | 427 |
| Master (outer) case height | 232 |
| Master (outer) case gross weight | 6210 |
| Products per master (outer) case | 3 |
