Legrand Keor ASI SP 600 FR uninterruptible power supply (UPS) Line-Interactive 0.6 kVA 360 W 2 AC outlet(s)
€109,95
Legrand Keor ASI SP 600 FR, Line-Interactive, 0.6 kVA, 360 W, Sine, 170 V, 280 V
Availability: Arriving Soon
The Keor SP is a single phase uninterruptible power supply with line interactive technology. It delivers a rated power of 600-800-1000-1500-2000VA, it is CPU-controlled and is equipped, internally, with valve-regulated, hermetically sealed lead accumulator batteries.The presence of an electronic stabilizer (AVR) inside the UPS provides the connected loads with effective protection against any interference in the electrical mains.
| Features | |
|---|---|
| UPS topology | Line-Interactive |
| Output power capacity | 0.6 kVA |
| Output power | 360 W |
| Waveform | Sine |
| Input operation voltage (min) | 170 V |
| Input operation voltage (max) | 280 V |
| Input frequency | 45/65 Hz |
| Output operation voltage (min) | 207 V |
| Output operation voltage (max) | 253 V |
| Output frequency | 50/60 Hz |
| Output frequency regulation | 1 Hz |
| Output voltage regulation | 10 % |
| Automatic Voltage Regulation (AVR) | Y |
| Number of input phases | 1 |
| Number of output phases | 1 |
| Efficiency | 96 % |
| Output power factor | 0.6 |
| Noise level | 40 dB |
| Surge protection | Y |
| Power protection features | Overcharge,Overdischarge,Overload,Short circuit |
| Audible alarm(s) | Y |
| Potential-free output | N |
| Auto shut-off | N |
| Power source type | AC |
| Ports & interfaces | |
| AC outlet types | C13 coupler,Type E |
| Power plug | C14 coupler |
| AC outlets quantity | 2 AC outlet(s) |
| USB port | Y |
| USB 2.0 ports quantity | 1 |
| USB port type | USB Type-B |
| Serial interface | N |
| Battery | |
| Battery technology | Sealed Lead Acid (VRLA) |
| Battery capacity | 7 Ah |
| Number of batteries supported | 1 |
| Design | |
| Form factor | Mini tower |
| Product colour | Black,White |
| LED indicators | Y |
| Operational conditions | |
| Operating temperature (T-T) | 0 - 40 °C |
| Operating relative humidity (H-H) | 0 - 95 % |
| Certificates | |
| Compliance certificates | CE |
| Certification | EN 62040-1, EN 62040-2 |
| Sustainability | |
| Sustainability compliance | Y |
| Weight & dimensions | |
| Width | 120 mm |
| Depth | 330 mm |
| Height | 138 mm |
| Weight | 5000 g |
| Packaging data | |
| Package width | 120 mm |
| Package depth | 5.46 mm |
| Package height | 138 mm |
| Package weight | 5295.3 g |
| Logistics data | |
| Products per pallet | 60 pc(s) |
| Pallet net height | 1350 mm |
| Pallet net length | 1000 mm |
| Pallet net width | 1200 mm |
| Pallet net weight | 334440 g |
| Master (outer) case width | 192 mm |
| Master (outer) case length | 392 mm |
| Master (outer) case height | 218 mm |
| Master (outer) case gross weight | 5574 g |
| Products per master (outer) case | 1 pc(s) |
