iiyama TE7512MIS-B4AG Signage Display Interactive flat panel 190.5 cm (75") LCD Wi-Fi 400 cd/m² 4K Ultra HD Black Touchscreen Built-in processor Android 24/7
iiyama TE7512MIS-B4AG, Interactive flat panel, 190.5 cm (75"), LCD, 3840 x 2160 pixels, Wi-Fi, 24/7
Availability:: Arriving soon
The TE7512MIS-B4AG is an exceptional 4K UHD interactive display designed by iiyama to enhance collaboration, communication, and engagement. With key features like Zero Airgap LCD DLED screen eliminating parallax, accurate PureTouch-IR, iiWare 13E with Android 14, WiFi and the iiyama DMS (Device management System), this display transforms the way you engage with content, making it an indispensable tool for modern workspaces and educational settings. Boasting a new 4K Interface with User Profiles for simple login and access to your very own bespoke application and Cloud Drives or harmonize with your existing estate and unleash the true power of Windows and Office applications. iiyama TE7512MIS-B4AG becomes a highly personalised & flexible device within a busy hybrid environment for multiple users. Share wirelessly more easily than ever before with iiyama Share and EShare app, bringing effortless ideation and efficient collaboration in your enterprise or school. This affordable display transforms the modern workplaces, educational institutions, dynamic meeting spaces and beyond. Elevate your interactive experience with the iiyama TE12 SERIES displays and embrace the future of visual communication.
| Display | |
|---|---|
| Panel type | VA |
| LED backlight | Y |
| LED backlighting type | Direct-LED |
| Display diagonal | 75 |
| Display technology | LCD |
| Display resolution | 3840 x 2160 |
| Display brightness | 400 |
| HD type | 4K Ultra HD |
| Touchscreen | Y |
| Touchscreen technology | PureTouch-IR |
| Number of simultaneous touchpoints | 40 |
| Multi-touch | Y |
| Native aspect ratio | 16:9 |
| Response time | 6.5 |
| Contrast ratio (typical) | 5000:1 |
| Contrast ratio (dynamic) | 8000:1 |
| Viewing angle, horizontal | 178 |
| Viewing angle, vertical | 178 |
| Display number of colours | 1.07 billion colours |
| Pixel pitch | 0.43 x 0.43 |
| Active display area (W x H) | 1650 x 928 |
| Display diagonal (metric) | 189.3 |
| Horizontal scan range | 30 - 135 |
| Native refresh rate | 60 |
| Surface hardness | 7H |
| Glass thickness | 3 |
| Ports & interfaces | |
| HDMI ports quantity | 3 |
| HDMI version | 2.0 |
| HDMI input ports quantity | 1 |
| HDMI output ports quantity | 1 |
| VGA (D-Sub) input ports | 1 |
| DisplayPorts quantity | 1 |
| DisplayPorts in | 1 |
| DisplayPort version | 1.2 |
| USB port | Y |
| USB ports quantity | 5 |
| USB version | 3.2 Gen 1 (3.1 Gen 1) |
| USB connector type | USB Type-A,USB Type-C |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity | 3 |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity | 2 |
| USB Power Delivery (USB PD) | Y |
| USB Power Delivery up to | 65 |
| Ethernet LAN (RJ-45) ports | 1 |
| PC Audio in | Y |
| RS-232C | Y |
| Remote (IR) input | 1 |
| Card reader integrated | Y |
| Compatible memory cards | MicroSD (TransFlash) |
| OPS module slot | Y |
| Audio Return Channel (ARC) | Y |
| Audio | |
| Built-in speaker(s) | Y |
| Number of built-in speakers | 2 |
| RMS rated power | 32 |
| Design | |
| Product design | Interactive flat panel |
| Placement supported | Indoor |
| Orientation | Horizontal |
| Product colour | Black |
| VESA mounting | Y |
| Panel mounting interface | 800 x 400 |
| Bezel width (bottom) | 45 |
| Bezel width (side) | 16.5 |
| Bezel width (top) | 16.5 |
| Bezel colour | Black |
| Anti-glare screen | Y |
| Mounting type | Wall |
| Performance | |
| Purpose | Universal |
| On Screen Display (OSD) | Y |
| Number of OSD languages | 14 |
| On Screen Display (OSD) languages | CZE,DAN,DEU,DUT,ENG,ESP,FIN,FRE,ITA,JPN,POL,RUS,SWE |
| Operating hours (hours/days) | 24/7 |
| HDCP | Y |
| HDCP version | 2.2 |
| Mean time between failures (MTBF) | 50000 |
| Power | |
| Power consumption (typical) | 174 |
| Power consumption (standby) | 0.4 |
| Power consumption (off) | 0.3 |
| Energy efficiency class (SDR) | G |
| Energy efficiency class (HDR) | Not available |
| Energy consumption (SDR) per 1000 hours | 174 |
| AC input voltage | 100 - 240 |
| AC input frequency | 50/60 |
| Energy efficiency scale | A to G |
| Computer system | |
| Computer system | Y |
| Built-in processor | Y |
| Processor manufacturer | ARM |
| Processor family | ARM Cortex |
| Processor architecture | ARM Cortex-A53+Cortex-A72 |
| Internal memory | 8 |
| On-board graphics card model | ARM Mali-G52 |
| Internal storage capacity | 128 |
| Operating system installed | Android |
| Operating system version | 14 |
| Weight & dimensions | |
| Display width | 1709 |
| Display depth | 98 |
| Display height | 1020 |
| Display weight | 39000 |
| Packaging data | |
| Package width | 1863 |
| Package depth | 1863 |
| Package height | 1148 |
| Package weight | 51500 |
| Packaging content | |
| Remote control included | Y |
| Batteries included | Y |
| Cables included | AC,HDMI,RS-232 |
| Operational conditions | |
| Operating temperature (T-T) | 0 - 40 |
| Storage temperature (T-T) | -20 - 60 |
| Certificates | |
| Certification | CB, CE, TÜV-Bauart, EAC, ErP, WEEE, REACH |
| Network | |
| Ethernet LAN | Y |
| Ethernet LAN data rates | 1000 |
| Wi-Fi | Y |
| Wi-Fi standards | Wi-Fi 6 (802.11ax) |
| Technical details | |
| OPS slot | 1 |
| Warranty period | 5 |
| Compliance certificates | RoHS |
| Other features | |
| Quick start guide | Y |
| Audio output | 3.5mm |
| Backlight type | Direct LED |
| Headphone connectivity | 3.5 mm |
| Headphone outputs | 1 |
| Power supply type | Internal |
| Housing material | Metal |
| Plug and Play | Y |
