D-Link 20km Long Range Wireless AC Bridge
D-Link 20km Long Range Wireless AC Bridge, Network bridge, 867 Mbit/s, Wi-Fi, Ethernet LAN, White
Availability:: Arriving soon
The power to deliver connectivity over an even longer distance.The DAP-3712 is the essential infrastructure wireless solution in providing high-speed connectivity to what was previously believed to be impossible-to-reach rural areas and challenging terrain.High-Gain Directional AntennaFast, stable, and long-range wireless coverage for up to 20 kmTDMA TechnologyHigh speeds and consistent coverage that filters out interferenceIP66 RatedWater-resistant and dust-tight housing boasts a longer product lifePoint-to-Point and Point-to-MultipointDistribute connectivity to single or multiple locations wirelessly over long distances8 kV Surge ProtectionYour device and network are protected against unexpected surges, such as lightningHigh-Speed Wi-FiBlazing speeds of up to 867 MbpsWi-Fi Security128-bit personal and enterprise wireless encryptionPoE ReadyPower over Ethernet makes for an easier installation with a single cableDesigned for Wireless ISPsRapid and cost-effective Internet distribution to get customers connectedThe power to withstand tough weatherThe DAP-3712 is enclosed in an unobtrusive IP66-rated housing, protecting it from rain and dirt. With built-in 8 kV surge protection, the DAP-3712 has protection against unexpected surges (such as lightning strikes), enabling it to be deployed where it’s needed, even in harsh environments and tough conditions.Bring connectivity to areas with limited or no access to fixed internet.The DAP-3712 features state-of-the-art hardware, including powerful high-gain 23 dBi directional antennas that effortlessly extend the coverage of 5GHz wireless AC speeds of up to 867Mbps to distances of up to 20 km away.Consistent coverage that filters out interferenceThe DAP-3712 supports TDMA technology, creating a schedule for the bridge's access point and the client. The sender and receiver are allocated a time slot for transmissions, eliminating hidden node data collisions, maximising airtime efficiency, significantly cutting down interference, and dramatically improving the transfer rate.Simple installation with Power over Ethernet (PoE)The DAP-3712 comes with a PoE injector included. No need to run extra power lines, no added hassle when configuring your hardwiring, and no more cable clutter.Free Next-Business-Day ServiceEnjoy our free Next Business Day service, as standard with D-Link Business products, to replace faulty equipment quickly.Our rapid-response technical support is designed to ensure businesses get the best support for their unique environment. Our extended warranty and enhanced service packages increases the lengths of warranties and further minimises downtime.
| Data transmission | |
|---|---|
| Maximum data transfer rate | 867 |
| Maximum transfer distance | 20000 |
| Antenna | |
| Antenna design | External |
| Antenna gain level (max) | 23 |
| Antennas quantity | 1 |
| Wireless LAN features | |
| Wi-Fi | Y |
| Wi-Fi band | Single-band (5 GHz) |
| WLAN data transfer rate (max) | 867 |
| Frequency band | 5.180 - 5.825 |
| Signal strength | 27 |
| Channels quantity | 2 |
| Network | |
| Ethernet LAN | Y |
| Ethernet LAN interface type | Gigabit Ethernet |
| Ethernet LAN data rates | 100,1000 |
| Networking standards | IEEE 802.11a,IEEE 802.11ac,IEEE 802.11n |
| Cabling technology | 10/100/1000Base-T(X) |
| Static IP | Y |
| Ports & interfaces | |
| Connectivity technology | Wired & Wireless |
| Ethernet LAN (RJ-45) ports | 1 |
| Security | |
| Security algorithms | 128-bit AES |
| MAC address filtering | Y |
| Management features | |
| Web-based management | Y |
| DHCP client | Y |
| Features | |
| Product type | Network bridge |
| Material | Acrylonitrile Butadiene Styrene (ABS) |
| Mounting type | Pole |
| Product colour | White |
| LED indicators | Signal strength |
| Automatic Transmit Power Control (ATPC) | Y |
| Reset button | Y |
| International Protection (IP) code | IP66 |
| Surge protection | Y |
| Power | |
| Power source type | PoE |
| Power consumption (typical) | 15 |
| Power consumption (max) | 15 |
| Power over Ethernet (PoE) | Y |
| Power over Ethernet (PoE) voltage | 48 |
| Operational conditions | |
| Operating temperature (T-T) | -40 - 65 |
| Operating relative humidity (H-H) | 0 - 90 |
| Storage temperature (T-T) | -40 - 85 |
| Storage relative humidity (H-H) | 0 - 90 |
| Certificates | |
| Compliance certificates | CE,Federal Communications Commission (FCC) |
| Certification | CE, FCC |
| Weight & dimensions | |
| Width | 372 |
| Depth | 241 |
| Height | 372 |
| Weight | 900 |
| Packaging data | |
| Quantity per pack | 1 |
| Logistics data | |
| Harmonized System (HS) code | 85176990 |
