APC Easy Rack PDU, Metered, 0U, 1 Phase, 7.4kW, 230V, 32A, 20 x C13 and 4 x C19 outlets, IEC60309 2P+E inlet
(0 review)Add your review
€978,04

APC Easy Rack PDU, Metered, 0U, 1 Phase, 7.4kW, 230V, 32A, 20 x C13 and 4 x C19 outlets, IEC60309 2P+E inlet, Metered, 0U, Single-phase, Vertical, Aluminium, Black

Availability: Arriving Soon
EAN:0731304405092Categories:PowerTags:

APC Easy Metered Rack PDU EPDU1132M is Easy-to-install and easy-to-use PDU, making rack power distribution easy and intelligent. This provides real-time remote monitoring, power management of connected loads, and much more features than the average power strip. EPDU1132M has IEC 60309 16A 2P+E type inlet, twenty IEC C13 and four IEC C19 type outlet sockets. This is integrated with Hydraulic-magnetic circuit breakers (in units with 32A input current). This is vertical rack mountable PDU in ultra light weight and smart, multifunctional new designed display. Easily mounts vertically in racks or enclosures and occupies zero U of valuable rack space, which allows more equipment in the rack. Full-featured user friendly network management web interface provides standards-based management via Web, SNMP, and Command Line Interface. Allows users to access, configure, and manage units from remote locations to save valuable time. Indicates overload and warning conditions based on the user-defined alarm thresholds. Alerts users of potential overloaded circuits. Quickly and easily upgrade firmware via network download for future product enhancements. Eliminates the need to replace products already installed in the field when new features are released. The packaging includes installation guide, user manual toolless mounting kit and vertical mounting brackets for quick and easy mounting in the enclosure. This can operate from -5° to +45°C temperation range and comes with 1 year of standard warranty.

Design
PDU typesMetered
TypeSingle-phase
Rack capacity0U
MountingVertical
Housing materialAluminium
Product colourBlack
DisplayLCD
On/off switchN
Ports & interfaces
AC outlets quantity24
Power plugIEC 60309
AC outlet typesC13 coupler,C19 coupler
Features
LED indicatorsY
Management features
Firmware upgradeableY
Power
Nominal input voltage200/208/230
AC input frequency50 - 60
Maximum current32
Nominal output voltage230
Load capacity7360
Maximum input current per phase32
Maximum power7360
Certificates
CertificationCE, TUV
Operational conditions
Operating temperature (T-T)-5 - 45
Storage temperature (T-T)-25 - 65
Operating relative humidity (H-H)5 - 95
Storage relative humidity (H-H)5 - 95
Operating altitude0 - 3000
Non-operating altitude0 - 15000
Weight & dimensions
Width62
Depth44
Height1175
Weight3720
Packaging content
ManualY
Packaging data
Package weight4480
Package width160
Package depth110
Package height1320
Logistics data
Total carbon footprint (kg of CO2e)28890.42
