LevelOne TURING 26-Port Web Smart Gigabit PoE Switch, 24 PoE Outputs, 2 x SFP/RJ45 Combo, 185W, 802.3at/af PoE
LevelOne TURING 26-Port Web Smart Gigabit PoE Switch, 24 PoE Outputs, 2 x SFP/RJ45 Combo, 185W, 802.3at/af PoE, Managed, L3, Gigabit Ethernet (10/100/1000), Power over Ethernet (PoE), Rack mounting
Availability: Arriving Soon
GEP-2651 Web Smart Gigabit PoE Switch is a next-generation Ethernet Switch offering powerful L2 features, Layer 3 Static Route, better PoE functionality and usability that delivers the cost-effectively business and transports Ethernet services via fiber or copper connections. GEP-2651 delivers 24 (10M/100M/1G) RJ45/PoE+ (Support 802.3at/af, and total up to 185W) ports and 2 Combo GbE RJ45/SFP ports. GEP-2651 provides high HW performance and environment flexibility for SMBs and Enterprises. GEP-2651 is ideal to deliver management simplicity, optimum user experience, and lower total cost of ownership. The embedded Device Managed System is designed to be extremely easy-to-use/manage/install IP Phone, IP Cam, or Wifi-AP for Enterprise Applications. Key Features- 24 PoE-Plus Gigabit Ethernet ports and 2 Gigabit SFP slots- QoS control for traffic prioritization and bandwidth management- DHCP Client/Server- Supports IPv4/IPv6 network operation- Minimize carbon footprint with advanced energy efficient technology (IEEE 802.3az)- IEEE 802.1d/w/s Spanning Tree Protocol (STP) and port mirroring- IP Multicast Filtering through IGMP Snooping V1 / V2 / V3- Supports port-based VLAN, IEEE 802.1Q VLAN Tagging- IEEE 802.3ad LACP for auto port aggregation
| Management features | |
|---|---|
| Switch type | Managed |
| Switch layer | L3 |
| Quality of Service (QoS) support | Y |
| Web-based management | Y |
| System event log | Y |
| Ports & interfaces | |
| Basic switching RJ-45 Ethernet ports quantity | 24 |
| Basic switching RJ-45 Ethernet ports type | Gigabit Ethernet (10/100/1000) |
| Gigabit Ethernet (copper) ports quantity | 24 |
| Combo SFP ports quantity | 2 |
| Network | |
| Networking standards | IEEE 802.1D,IEEE 802.1Q,IEEE 802.1p,IEEE 802.1w,IEEE 802.1x,IEEE 802.3,IEEE 802.3ab,IEEE 802.3ad,IEEE 802.3af,IEEE 802.3at,IEEE 802.3az,IEEE 802.3u,IEEE 802.3z |
| Copper ethernet cabling technology | 100BASE-TX,1000BASE-T |
| Port mirroring | Y |
| Flow control support | Y |
| Link aggregation | Y |
| Broadcast storm control | Y |
| Spanning tree protocol | Y |
| Cable length detection | Y |
| MAC address auto-learning supported | Y |
| MAC address auto-aging supported | Y |
| VLAN support | Y |
| Virtual LAN features | Tagged VLAN,MAC address-based VLAN,Port-based VLAN |
| Number of VLANs | 256 |
| Optical fiber | |
| Fiber ethernet cabling technology | 1000BASE-X |
| Data transmission | |
| Switching capacity | 52 |
| Forwarding rate | 38.7 |
| MAC address table | 8000 |
| Store-and-forward | Y |
| Static route | Y |
| Jumbo frames support | Y |
| Jumbo frames | 9600 |
| Security | |
| DHCP features | DHCP server,DHCP snooping,DHCP client |
| Access Control List (ACL) | Y |
| IGMP snooping | Y |
| Security algorithms | 802.1x RADIUS |
| Static port security | Y |
| Loop protection | Y |
| BPDU filtering/protection | Y |
| Protocols | |
| Supported network protocols | IPv4/IPv6 |
| Design | |
| Rack mounting | Y |
| Product colour | Black |
| Reset button | Y |
| LED indicators | Activity,Link,PoE,Speed |
| Safety | UL 60950-1, 2nd Edition, 2014-10-14, CAN/CSA C22.2 No. 60950-1-07, 2nd Edition, 2014-10 |
| Performance | |
| Internal memory | 128 |
| Flash memory | 32 |
| Firmware upgradeable | Y |
| Buffer size | 512 |
| Mean time between failures (MTBF) | 211272 |
| Power | |
| AC input voltage | 100 - 240 |
| AC input frequency | 50 - 60 |
| Power consumption (typical) | 18.29 |
| Power over Ethernet (PoE) | |
| Power over Ethernet (PoE) | Y |
| Power over Ethernet plus (PoE+) ports quantity | 24 |
| Power over Ethernet (PoE) power per port | 30 |
| Total Power over Ethernet (PoE) budget | 185 |
| Operational conditions | |
| Operating temperature (T-T) | 0 - 45 |
| Storage temperature (T-T) | -20 - 70 |
| Operating relative humidity (H-H) | 10 - 90 |
| Storage relative humidity (H-H) | 10 - 90 |
| Weight & dimensions | |
| Width | 442 |
| Depth | 211 |
| Height | 44 |
| Weight | 3100 |
| Packaging content | |
| Cables included | AC |
| Quick start guide | Y |
| Manual | Y |
| Packaging data | |
| Package width | 300 |
| Package depth | 520 |
| Package height | 90 |
| Package weight | 3500 |
| Certificates | |
| Certification | CE, FCC Part 15 Class A, RoHS |
| Logistics data | |
| Country of origin | Taiwan |
| Master (outer) case width | 482 |
| Master (outer) case length | 540 |
| Master (outer) case height | 324 |
| Harmonized System (HS) code | 85176990 |
| Master (outer) case gross weight | 21000 |
| Products per master (outer) case | 5 |
