ATEN CL3000N rack console 48.3 cm (19") 1280 x 1024 pixels Metal, Plastic Black 1U
ATEN CL3000N, 48.3 cm (19"), 1280 x 1024 pixels, LCD, 250 cd/m², 1000:1, 170°
Availability: Arriving Soon
The CL3000 Lightweight PS/2-USB LCD Console is a LCD KVM console that serves as the front end console for compatible KVM switches.Lightweight and with a 19” power-saving LED-backlit LCD, the CL3000 offers a space-saving, streamlined approach to KVM switch technology by integrating a keyboard, LED-backlit LCD monitor, and touchpad in a 1U housing.In addition, testing is performed utilizing the MIL-STD-810G* (Method 514.6, Procedure 1, Category 4 Common Carrier) procedure for Vibration Certification. MIL-STD-810G testing provides proven reliable operations of the CL3000 in harsh environments, by using advanced testing to emphasize the equipment's environmental design and limits in real world conditions that it will experience throughout its life; such as operating in a moving vehicle or on a factory floor where high vibrations occur often.*MIL-STD-810G Method 514.6, Procedure I, Category4(Common Carrier, US Highway Truck Vibration Exposure) Exposed to random vibration tests at different levels based on axes from 5 to 500Hz, for one hour per axis. Total levels applied are 1.07Grms vertical axis (Z axis), 0.76Grms transverse axis (Y axis), and 0.76Grms longitudinal axis (X axis)Note: Optional rack mount kits are available. For more information, refer to Compatible Accessories below.
| Display | |
|---|---|
| Display diagonal | 19 |
| Display resolution | 1280 x 1024 |
| Display | LCD |
| Display brightness | 250 |
| Contrast ratio (typical) | 1000:1 |
| Viewing angle, horizontal | 170 |
| Viewing angle, vertical | 160 |
| Pixel pitch | 0.294 x 0.294 |
| Display type | TFT |
| Response time | 5 |
| Display number of colours | 16.78 million colours |
| Supported resolutions | 1920 x 1200 @ 60Hz; 1280 x 1024 @ 75 Hz, DDC2B |
| Technical details | |
| Material | Metal,Plastic |
| Product colour | Black |
| Operating relative humidity (H-H) | 0 - 80 |
| Built-in KVM switch | Y |
| KVM switch ports quantity | 1 |
| Maximum resolution | 1920 x 1200 |
| Rack mounting | Y |
| Number of computers controlled | 1 |
| On/off switch | Y |
| LED indicators | Y |
| Push button | Y |
| Compliance certificates | RoHS |
| Rack capacity | 1U |
| Ports & interfaces | |
| VGA (D-Sub) ports quantity | 1 |
| I/O ports | 1x SPHD |
| Keyboard port type | PS/2 |
| Mouse port type | PS/2 |
| Video port type | VGA |
| USB 2.0 Type-A ports quantity | 3 |
| Keyboard | |
| Built-in touchpad | Y |
| Keyboard language | Nordic |
| Keyboard layout | QWERTY |
| Hot keys | Y |
| Power | |
| Power consumption (typical) | 22.7 |
| AC adapter input voltage | 100 - 240 |
| AC adapter frequency | 50/60 |
| Input current | 1 |
| AC (power) in | Y |
| Operational conditions | |
| Operating temperature (T-T) | 0 - 50 |
| Storage temperature (T-T) | -20 - 60 |
| System requirements | |
| Windows operating systems supported | Y |
| Mac operating systems supported | Y |
| Linux operating systems supported | Y |
| Other operating systems supported | SunOS |
| Weight & dimensions | |
| Width | 585.2 |
| Height | 44 |
| Depth | 480 |
| Weight | 9000 |
| Packaging content | |
| Cables included | AC,KVM |
| Quick installation guide | Y |
| Manual | Y |
| Rack mount kit | Y |
