PATCHBOX .one / 30RU / UTP / White
PATCHBOX .one / 30RU / UTP / White, 1.8 m, Cat6a, U/UTP (UTP), RJ-45, RJ-45, White
Availability: Arriving Soon
The Ultimate Cable Management SolutionThe patchbox.one with its retractable Cat.6a cables is the ultimate solution for keeping your network rack forever organized, efficient, and future-proof. It is equipped with super-flexible twisted pair cables that are retractable, lighter and easier to handle.Say Goodbye to Cable ChaosWith 24 retractable cables neatly stored inside modular cassettes, your rack stays tidy, reducing clutter and improving airflow.Up to 50% More Usable Rack SpaceBy storing excess cable length where it doesn’t bother you and removing conventional cable managers, patchbox.one frees up precious rack space.10x Faster Installation & TroubleshootingEvery cable retracts to your desired length—no measuring, no zip ties. IT Technicians can work significantly faster and more accurately and downtimes can be reduced by up to 90%.High-Speed, PoE-Ready PerformanceCat.6a cables meet ISO/IEC 11801 Class Ea standards and support PoE (STP) and PoE++ (UTP), ready to power your devices.Color-Code for Instant OverviewChoose from 8 different cable colors—ideal for cable-coding your rack setup.Optimized for Your Rack SizeWhile our 8RU version includes 0.8m cables for compact racks, the 30RU version comes with 1.8m cables, ideal for full-height network cabinets.Modular and CustomizableCassettes can be replaced or rearranged in seconds—adapt to your changing infrastructure without starting over.Built to Last, Backed by Warrantypatchbox.one and all cables come with a 10-Year Warranty, delivering reliability you can trust in mission-critical environments.
| Features | |
|---|---|
| Product colour | White |
| Cable length | 1.8 |
| Cable standard | Cat6a |
| Cable shielding | U/UTP (UTP) |
| Connector 1 | RJ-45 |
| Connector 2 | RJ-45 |
| Connector 1 gender | Male connector |
| Connector 2 gender | Male connector |
| Connector contacts plating | Gold |
| Jacket material | Polyvinyl chloride (PVC) |
| Cable shape | Flat |
| Conductor material | Copper |
| Networking standards | IEEE 802.3bt |
| AWG wire size | 30 |
| Data transfer rate | 10000 |
| Bend radius (min) | 12 |
| Power over Ethernet (PoE) | Y |
| Power over Ethernet (PoE) type supported | PoE++ (4PPoE) |
| Country of origin | Hungary |
| Operational conditions | |
| Operating temperature (T-T) | -20 - 60 |
| Operating relative humidity (H-H) | 10 - 90 |
| Certificates | |
| Certification | ISO/IEC 11801 Channel Class Ea, ANSI/EIA/TIA-568 Cat 6A Channel |
| Weight & dimensions | |
| Width | 482 |
| Depth | 600 |
| Height | 44 |
| Weight | 7080 |
| Packaging content | |
| Quantity per pack | 1 |
| Packaging content | 24 x patchbox.one / Cassette / 30RU / UTP / White 1 x patchbox.one / Frame 4 x Flanges 4 x Hex nuts 6 x Patchcatch 2 x Mounting rails |
| Packaging data | |
| Package width | 799 |
| Package depth | 587 |
| Package height | 55 |
| Package weight | 8560 |
| Other features | |
| Cables included | LAN (RJ-45) |
