Sony VPL-EW575 data projector Standard throw projector 4300 ANSI lumens 3LCD WXGA (1280x800) Black, White
Sony VPL-EW575, 4300 ANSI lumens, 3LCD, WXGA (1280x800), 16:10, 762 - 7620 mm (30 - 300"), 20000:1
Availability:: Arriving soon
Present clear, bright images, with flexible connectivity and low running costsThe VPL-EW575 projector is ideal for mid-sized classrooms and meeting rooms.Quiet, compact and powerful, it delivers detail-packed WXGA images with 4,300 lumens colour light output and high 20,000:1 contrast ratio that can be seen clearly even in bright rooms and with larger projection screens, with Sony's 3LCD technology assuring natural, vivid colours. Image quality is further improved compared with previous models, with a new colour/white balance setting for crisp reproduction of on-screen text and a new 'Vivid' picture mode ensuring even richer, more vibrant colours.The VPL-EW575 is an ideal partner for today's integrated AV/IT environments, expanding your connectivity options with dual HDMI ports and Direct USB Display connection. A convenient input label function makes life simpler, confirming on screen the name of connected devices.Add the VPL-EW575 to a network and see presentations from up to four connected PC/Mac computers simultaneously. Slip in an optional Wi-Fi dongle and present directly wirelessly from laptops.A range of energy-saving features plus up to 10,000 hours recommended lamp replacement time contribute to low ownership costs. Routine maintenance is quick and easy with a convenient rear lamp access feature.
| Projector | |
|---|---|
| Screen size compatibility | 30 - 300 " |
| Contrast ratio (dynamic) | 20000:1 |
| Projector brightness | 4300 ANSI lumens |
| Projection technology | 3LCD |
| Projector native resolution | WXGA (1280x800) |
| Native aspect ratio | 16:10 |
| Projector brightness (economic mode) | 2400 ANSI lumens |
| Horizontal scan range | 15 - 92 kHz |
| Vertical scan range | 48 - 92 Hz |
| Keystone correction, vertical | -20 - 20 ° |
| Matrix size | 0.75 " |
| Heat dissipation | 1133 BTU/h |
| Light source | |
| Light source type | Lamp |
| Service life of light source | 4000 h |
| Service life of light source (economic mode) | 10000 h |
| Lamp type | UHM |
| Lamp power | 225 W |
| Lens system | |
| Focus | Manual |
| Zoom capability | Y |
| Zoom type | Manual |
| Zoom ratio | 1.6:1 |
| Throw ratio | 1.10 - 1.79:1 |
| Video | |
| Analog signal format system | NTSC,NTSC 3.58,NTSC 4.43,PAL,PAL 60,PAL M,PAL N,SECAM |
| 3D | N |
| Supported graphics resolutions | 1600 x 1200 (UXGA) |
| Supported video modes | 480i,480p,576i,576p,720p,1080i,1080p |
| Ports & interfaces | |
| HDMI connector type | Full-size |
| S-Video inputs quantity | 1 |
| HDBaseT port | Y |
| USB 2.0 ports quantity | 2 |
| Microphone in | Y |
| Serial interface type | RS-232C |
| VGA (D-Sub) ports quantity | 1 |
| HDMI ports quantity | 2 |
| Composite video in | 1 |
| Component video (YPbPr/YCbCr) in | 1 |
| DVI port | N |
| AC (power) in | Y |
| Network | |
| Ethernet LAN | Y |
| Ethernet LAN (RJ-45) ports | 1 |
| Ethernet LAN data rates | 10,100 Mbit/s |
| Wi-Fi | N |
| Storage | |
| Card reader integrated | N |
| Features | |
| Noise level (economic mode) | 29 dB |
| HDCP | Y |
| On Screen Display (OSD) | Y |
| On Screen Display (OSD) languages | ARA,CHI (SIMPL),CHI (TR),CZE,DEU,DUT,ENG,ESP,FAS,FIN,FRE,GRE,HUN,IND,ITA,JPN,KOR,NOR,POL,POR,RUM,RUS,SLV,SWE,THA,TUR,VIE |
| Multimedia | |
| Built-in speaker(s) | Y |
| RMS rated power | 16 W |
| Design | |
| Market positioning | Portable |
| Product type | Standard throw projector |
| Product colour | Black,White |
| Placement | Desktop,Ceiling |
| Display | |
| Built-in display | N |
| Power | |
| Power source | AC |
| Power consumption (typical) | 319 W |
| Power consumption (standby) | 0.5 W |
| Power consumption (max) | 332 W |
| Power consumption (network standby) | 6.6 W |
| AC input voltage | 100 - 240 V |
| AC input frequency | 50 - 60 Hz |
| Operational conditions | |
| Operating temperature (T-T) | 0 - 40 °C |
| Storage temperature (T-T) | -10 - 60 °C |
| Operating relative humidity (H-H) | 20 - 80 % |
| Storage relative humidity (H-H) | 20 - 80 % |
| Weight & dimensions | |
| Width | 365 mm |
| Depth | 252 mm |
| Height | 96.2 mm |
| Weight | 4100 g |
| Packaging content | |
| Remote control included | Y |
| Other features | |
| RS-232 ports | 1 |
| RS-232C | Y |
