Chieftec Value APB-700B8 power supply unit 700 W 20+4 pin ATX ATX Silver
€70,07
Chieftec Value APB-700B8, 700 W, 200 - 240 V, 47 - 63 Hz, 5 A, Active, 130 W
Availability: Arriving Soon
The new VALUE SERIES offers both quality and 80 PLUS® 230V EU efficiency at a highly competitive pricing. Equipped with a vast amount of required connectors, long native cables and a silent running fan with installed thermal board, the PSU runs quietly on full load and provides REAL POWER, thereby providing all security features. Certified by CE, CB, EAC, TÜV and amongst many others, it’s the VALUE choice!
| Power | |
|---|---|
| Total power | 700 |
| AC input voltage | 200 - 240 |
| AC input frequency | 47 - 63 |
| Input current | 5 |
| Power factor | 0.9 |
| Power Factor Correction (PFC) type | Active |
| Combined power (+3.3V) | 130 |
| Combined power (+12V) | 648 |
| Combined power (+5V) | 130 |
| Max output current (+3.3V) | 22 |
| Max output current (+12V1) | 54 |
| Max output current (+5V) | 22 |
| Power protection features | Over voltage,Overheating,Overload,Short circuit,Under power,Under voltage |
| Ports & interfaces | |
| Motherboard power connector | 20+4 pin ATX |
| Motherboard power cable length | 550 |
| Number of SATA power connectors | 4 |
| SATA power cable length | 150,550 |
| Peripheral (Molex) power connectors (4-pin) | 2 |
| Peripheral (Molex) power cable length | 150,500 |
| EPS power connector (4+4 pin) | Y |
| PCI Express power connectors (6+2 pin) | 2 |
| PCI Express power cable length | 500 |
| CPU power connector (4+4 pin) | Y |
| CPU power cable length | 500 |
| Floppy drive power connector | 1 |
| Floppy disk drive connector | Y |
| Cabling type | Non-Modular |
| Performance | |
| 80 PLUS certification | 80 PLUS |
| Purpose | PC/server |
| Power supply unit (PSU) form factor | ATX |
| ATX version | 2.3 |
| Design | |
| Product colour | Silver |
| Cooling type | Active |
| Fan diameter | 120 |
| Number of fans | 1 |
| Certificates | |
| Compliance certificates | CE |
| Certification | CE, CB, EAC, TÜV |
| Weight & dimensions | |
| Width | 150 |
| Depth | 140 |
| Height | 87 |
| Weight | 1420 |
| Packaging data | |
| Package weight | 1570 |
| Technical details | |
| Sustainability compliance | Y |
| Logistics data | |
| Harmonized System (HS) code | 84733020 |
