GIGABYTE X670E AORUS XTREME Motherboard - Supports AMD 9000 Series CPUs, 18+2+2 Phases Digital VRM, up to 8000MHz DDR5 (OC), 4xPCIe 5.0 M.2, Wi-Fi 6E, 10GbE LAN, USB 3.2 Gen 2x2

€780,63

GIGABYTE X670E AORUS XTREME Motherboard - Supports AMD 9000 Series CPUs, 18+2+2 Phases Digital VRM, up to 8000MHz DDR5 (OC), 4xPCIe 5.0 M.2, Wi-Fi 6E, 10GbE LAN, USB 3.2 Gen 2x2, AMD, Socket AM5, AMD Ryzen™ 7, 192 GB, DDR5-SDRAM, 192 GB

Availability:: Arriving soon

Add to Cart

Add to wishlist

Compare

EAN:4719331848774Categories:Hardware Components

Elevate your computing experience with GIGABYTE's renowned motherboard series: AORUS, AERO, and GIGABYTE. Featuring innovative designs and advanced features, these boards offer exceptional performance and reliability. Whether you're a gamer, content creator, or professional, our series cater to your needs, ensuring uncompromising quality and cutting-edge

Processor
Processor manufacturer	AMD
Processor socket	Socket AM5
Compatible processor series	AMD Ryzen 7
Maximum number of SMP processors	1
Maximum internal memory supported by processor	192
Memory
Supported memory types	DDR5-SDRAM
Number of memory slots	4
Memory slots type	DIMM
Memory channels	Dual-channel
Supported memory clock speeds	4400,4800,5200,5600,6000,6200,6400,6600,6666,6800,7000,7200,7600,7800,8000
Supported memory clock speed (max)	8000
Maximum internal memory	192
Storage controllers
Supported storage drive types	HDD & SSD
Supported storage drive interfaces	M.2,SATA II
Number of HDDs supported	6
Number of storage drives supported	10
RAID levels	0,1,10
Graphics
Parallel processing technology support	Crossfire
DirectX version	12.0
Internal I/O
USB 2.0 connectors	2
USB 3.2 Gen 1 (3.1 Gen 1) connectors	2
USB 3.2 Gen 2x2 connectors	1
Number of SATA III connectors	6
Total number of SATA connectors	6
Audio connector	Y
Front panel connector	Y
CPU fan connector	Y
Chassis intrusion connector	Y
RGB LED pin header	Y
Rear panel I/O ports
USB 2.0 ports quantity	4
USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity	6
USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity	1
USB 3.2 Gen 2x2 Type-C ports quantity	1
Ethernet LAN (RJ-45) ports	1
HDMI ports quantity	1
HDMI version	2.0
S/PDIF out port	Y
Network
Ethernet LAN	Y
Ethernet interface type	2.5 Gigabit Ethernet
Wi-Fi	Y
Top Wi-Fi standard	Wi-Fi 6E (802.11ax)
Wi-Fi standards	802.11a,802.11b,802.11g,Wi-Fi 4 (802.11n),Wi-Fi 5 (802.11ac),Wi-Fi 6 (802.11ax),Wi-Fi 6E (802.11ax)
WLAN controller model	Intel Wi-Fi 6E AX210
Bluetooth	Y
Bluetooth version	5.3
Features
Motherboard chipset	AMD X670
Audio output channels	7.1
Component for	PC
Motherboard form factor	ATX
Motherboard chipset family	AMD
Windows operating systems supported	Windows 10 Home x64,Windows 11 x64
Expansion slots
PCI Express x16 (Gen 3.x) slots	1
PCI Express x16 (Gen 4.x) slots	1
Number of M.2 (M) slots	4
BIOS
BIOS type	UEFI AMI
BIOS memory size	256
ACPI version	5.0
Clear CMOS jumper	Y
Clear CMOS button	Y
Desktop Management Interface (DMI) version	2.7
System Management BIOS (SMBIOS) version	2.7
Logistics data
Country of origin	Taiwan
Products per shipping (inner) case	1
Battery
Battery weight	3
Lithium weight per battery	0.07
Number of battery cells	1
Battery technology	Lithium-Manganese Dioxide (LiMnO2)
Battery type	CR2032
Packaging data
Package width	255
Package depth	350
Package height	445
Package weight	4540
Weight & dimensions
Width	305
Depth	269
Height	35
Packaging content
Cables included	SATA
Batteries included	Y
Drivers included	Y
Technical details
Warranty period	3
