ATEN 16 x 16 Modular Matrix Switch

(0 reviews)Add your review

€5030,62

ATEN 16 x 16 Modular Matrix Switch, Modular AV matrix switchers, 15.2 Gbit/s, Black, Metal, 6U, 460 W

Availability:: Arriving soon

Add to Cart

Add to wishlist

Compare

EAN:4719264646287Categories:Networking

The ATEN Modular Matrix Solution Series comprises the VM1600A/VM3200 Modular Matrix Switch in tandem with a range of hot-swappable I/O boards. The solution offers real-time control and advanced access to manage 16/32 video sources and 16/32 displays simultaneously, through modular I/O boards in a single chassis. Empowered by ATEN Seamless Switch™ technology, the VM1600A/VM3200 video matrix switches incorporate a speed-progressive video switching function and a unique scaler that integrates seamlessly with video wall systems.1x VM1600A Modular Matrix Switch1x LIN2-418K-E12G Power Cord1x Terminal Block connector1x VM-FAN554 Fan Module (pluggable)1x VM-PWR460 Power Module (pluggable)1x User Instructions

Features
Product type	Modular AV matrix switchers
Data transfer rate	15.2
EDID management	Y
Design
Housing colour	Black
Housing material	Metal
Rack mounting	Y
Rack capacity	6U
LED indicators	Y
Display
Built-in display	Y
Ports & interfaces
RJ-45 input ports	1
RS-232 ports	1
Power
Power consumption (max)	460
AC input voltage	100 - 240
AC input frequency	50 - 60
Input current	6
Operational conditions
Operating temperature (T-T)	0 - 40
Storage temperature (T-T)	-20 - 60
Operating relative humidity (H-H)	0 - 80
Logistics data
Products per master (outer) case	1
Master (outer) case gross weight	18260
Master (outer) case length	579
Master (outer) case width	518
Master (outer) case height	390
Master (outer) case net weight	17570
Harmonized System (HS) code	85299097
Weight & dimensions
Width	466.6
Depth	482
Height	265.9
Weight	17570
Package width	518
Package depth	579
Package height	390
Package weight	18260
Packaging content
Cables included	AC
