ATEN AT-VM0808
ATEN AT-VM0808, VGA, Metal, Black, 1920 x 1440, 1280 x 1024 (SXGA), 1600 x 1200 (UXGA), 1920 x 1200 (WUXGA), 800 x 600 (SVGA), 500 MHz, 1920 x 1440 pixels
Availability:: Arriving soon
The ATEN VanCryst VM0808 8x8 Video Matrix Switch allows you to connect eight VGA source devices to eight VGA monitors, displays, or projectors at the same time. It’s steadfast unique features include: Ultra-high bandwidth, EDID mode selection for high compatibility, long signal range, easy source/display switching, matrix connections, Power On Detection for source/display loss prevention.As a Matrix Switch, each input can be independently connected to any or all outputs, and the audio and video inputs from each source device can also be switched independently, giving you the ultimate in flexibility and control in any multi-display audio/video installation.
| Ports & interfaces | |
|---|---|
| Video port type | VGA |
| VGA (D-Sub) ports quantity | 16 |
| RS-232 ports | 1 |
| Features | |
| Material | Metal |
| Product colour | Black |
| Supported graphics resolutions | 1920 x 1440,1280 x 1024 (SXGA),1600 x 1200 (UXGA),1920 x 1200 (WUXGA),800 x 600 (SVGA) |
| LED indicators | Y |
| Bandwidth | 500 |
| Maximum resolution | 1920 x 1440 |
| Power | |
| Power requirements | 100-230V AC |
| Weight & dimensions | |
| Weight | 2480 |
| Dimensions (WxDxH) | 168.5 x 437.2 x 44 |
| Packaging content | |
| Packaging content | - 1x VM0808 8x8 Video Matrix Switch - 1x Power Cord - 1x IR Remote Control - 1x IR Receiver - 1x Mounting Kit - 1x User Instructions |
