ATEN 4 x 2 True 4K Presentation Matrix Switch
€685,31
ATEN 4 x 2 True 4K Presentation Matrix Switch, Media presentation matrix switcher, 4096 x 2160 pixels, 4096 x 2160, 3840 x 2160, Black, Metal, Buttons
Availability:: Arriving soon
1x VP1420 4 x 2 True 4K Presentation Matrix Switch1x 2XRT-0003G IR Receiver1x 2XRT-0111G IR Remote Control2x 3-pole Terminal Blocks2x 5-pole Terminal Blocks1x 0AD8-1005-26M1 Power Adaptor1x User Instructions
| Features | |
|---|---|
| Product type | Media presentation matrix switcher |
| Maximum resolution | 4096 x 2160 |
| HDCP | Y |
| HDCP version | 2.2 |
| 3D | Y |
| Extended display identification data (EDID) | Y |
| Supported resolutions | 4096 x 2160, 3840 x 2160 |
| Design | |
| Housing colour | Black |
| Housing material | Metal |
| Control type | Buttons |
| On/off switch | Y |
| LED indicators | Y |
| Remote control included | Y |
| Display | |
| Built-in display | N |
| Ports & interfaces | |
| HDMI input ports quantity | 3 |
| HDMI output ports quantity | 2 |
| VGA (D-Sub) input ports | 1 |
| RJ-45 input ports | 1 |
| Remote (IR) input | 1 |
| DC-in jack | Y |
| Power | |
| Power consumption (typical) | 7.21 |
| Operational conditions | |
| Operating temperature (T-T) | 0 - 40 |
| Storage temperature (T-T) | -20 - 60 |
| Operating relative humidity (H-H) | 0 - 80 |
| Storage relative humidity (H-H) | 0 - 80 |
| Logistics data | |
| Products per master (outer) case | 3 |
| Master (outer) case gross weight | 6370 |
| Master (outer) case length | 427 |
| Master (outer) case width | 370 |
| Master (outer) case height | 232 |
| Master (outer) case net weight | 4170 |
| Harmonized System (HS) code | 85299097 |
| Weight & dimensions | |
| Width | 160.5 |
| Depth | 200 |
| Height | 44 |
| Weight | 1390 |
| Package width | 207 |
| Package depth | 414 |
| Package height | 117 |
| Package weight | 1850 |
| Packaging content | |
| Quick start guide | Y |
| AC adapter included | Y |
| IR receiver included | Y |
