Vertiv Liebert GXE3-10KIRT5UXL uninterruptible power supply (UPS) Double-conversion (Online) 10 kVA 10000 W
Vertiv Liebert GXE3-10KIRT5UXL, Double-conversion (Online), 10 kVA, 10000 W, Pure sine, 178 V, 288 V
Availability: Arriving Soon
The Vertiv Liebert GXE UPS is an affordable, efficient UPS designed for delivering best-in-class power protection to equipment at the edge of networks or in remote sites. This 10000 VA UPS offers online double conversion solution. Its unity output power factor (1.0) enables continuous and reliable power to more connected devices. The high efficiency in both online and ECO modes of operation (up to 98% in ECO mode) for this already affordable UPS further drives energy and operational costs savings. Additional external battery cabinets provide scalable runtime for those applications requiring longer period of backup in case of AC mains failures. This single-phase UPS can be mounted as a tower or placed inside a rack cabinet, with a gravity sensing LCD display to allow rack/tower configurations. It has remote management capability with optional network management cards. With proven reliability, it is ideal for critical applications in financial, government, and manufacturing industries.
| Features | |
|---|---|
| UPS topology | Double-conversion (Online) |
| Output power capacity | 10 |
| Output power | 10000 |
| Waveform | Pure sine |
| Input operation voltage (min) | 178 |
| Input operation voltage (max) | 288 |
| Input frequency | 40/70 |
| Output operation voltage (min) | 220 |
| Output operation voltage (max) | 230 |
| Surge energy rating | 600 |
| Efficiency (On-line mode) | 94 |
| Efficiency (ECO mode) | 98 |
| Emergency Power Off (EPO) | Y |
| EMI/RFI noise filtering | 58 |
| Power protection features | Overload |
| Audible alarm(s) | Y |
| Ports & interfaces | |
| USB port | Y |
| Battery | |
| Battery technology | Sealed Lead Acid (VRLA) |
| Battery life (max) | 5 |
| Design | |
| Form factor | Tower |
| Rack capacity | 5U |
| Product colour | Black |
| Display type | LCD |
| Operational conditions | |
| Operating temperature (T-T) | 0 - 40 |
| Storage temperature (T-T) | -20 - 70 |
| Operating relative humidity (H-H) | 5 - 95 |
| Certificates | |
| Compliance certificates | REACH,RoHS,WEEE |
| Certification | CE, UKCA, Morocco, RCM, CB report, EAC |
| Packaging content | |
| Rack mount kit | Y |
| Cables included | USB cable |
| Quick installation guide | Y |
| Weight & dimensions | |
| Width | 430 |
| Depth | 700 |
| Height | 217 |
| Weight | 80000 |
| Packaging data | |
| Package width | 600 |
| Package depth | 800 |
| Package height | 530 |
| Package weight | 102000 |
| Logistics data | |
| Country of origin | China |
| Other features | |
| Nominal input voltage | 230 |
