ATEN HDMI Video Repeater with Audio De-embedder
ATEN HDMI Video Repeater with Audio De-embedder, 1920 x 1080 pixels, AV repeater, 15 m, Wired, 3D, HDCP
Availability:: Arriving soon
The VC880 is an HDMI Repeater with an added audio de-embedder that extracts and converts the audio signal from the HDMI input. This means that as well as the repeated HDMI audio and video signal output, users can also choose between analog stereo audio via RCA connectors or digital audio via optical or coaxial connectors as an additional high quality audio output. With support for 3D TV formats, the VC880 is ideal for users who want to enjoy high defi nition video with their choice of high defi nition audio output on TVs, projectors, A/V receivers or speakers.1x VC880 HDMI Repeater Plus Audio De-embedder1x 0AD6-1605-09EG Power Adapter1x User Instructions
| Features | |
|---|---|
| Type | AV repeater |
| Maximum resolution | 1920 x 1080 |
| Maximum transfer distance | 15 |
| Maximum refresh rate | 60 |
| Supported video modes | 1080p |
| Supported graphics resolutions | 1920 x 1080 (HD 1080) |
| Bandwidth | 225 |
| HDCP | Y |
| Material | Metal |
| 3D | Y |
| Firmware upgradeable | Y |
| Impedance | 100 |
| HDCP version | 1.1 |
| Product colour | Black |
| Ports & interfaces | |
| Connectivity technology | Wired |
| HDMI in | 1 |
| Number of HDMI outputs | 1 |
| Digital audio optical out | 1 |
| Audio (L/R) out | 1 |
| DC-in jack | Y |
| Power | |
| Operating voltage | 5.3 |
| Power consumption (typical) | 2.25 |
| Operational conditions | |
| Operating temperature (T-T) | 0 - 50 |
| Storage temperature (T-T) | -20 - 60 |
| Operating relative humidity (H-H) | 0 - 80 |
| Storage relative humidity (H-H) | 0 - 80 |
| Weight & dimensions | |
| Width | 200 |
| Depth | 82 |
| Height | 25 |
| Weight | 520 |
| Packaging data | |
| Quantity per pack | 1 |
| Package width | 59 |
| Package depth | 239 |
| Package height | 160 |
| Package weight | 700 |
| Packaging content | |
| AC adapter included | Y |
| Manual | Y |
| Logistics data | |
| Master (outer) case width | 315 |
| Master (outer) case length | 490 |
| Master (outer) case height | 338 |
| Master (outer) case gross weight | 14650 |
| Master (outer) case net weight | 10400 |
| Products per master (outer) case | 20 |
