TP-Link 5-Port 2.5G Desktop Switch
TP-Link 5-Port 2.5G Desktop Switch, Unmanaged, 2.5G Ethernet (100/1000/2500)
Availability: Arriving Soon
Upgrade to a Super-Fast, Futuristic Network5/8-Port 2.5G Desktop SwitchTL-SG105-M2/ TL-SG108-M2Unlock the Highest Performance of2.5G Multi-Gig Bandwidth and DevicesAs the flagship 2.5G products, the 5/8-Port desktop switches with 5/8× 2.5-Gigabit ports unlock the highest performance of your Multi-Gig bandwidth and devices, and provide up to 25/40 Gbps of switching capacity. Auto-negotiation 3-speed (100Mb/1G/2.5G) connections sense the link speeds and intelligently adjust for compatibility and optimal performance for all your devices, including 2.5G NAS, 2.5G PCIe adapter, gaming console, VR gaming, 2.5G WiFi 6 AP, 4K video, desktop, and more.Powerful Performance for Smooth LAN PartiesNever host a laggy LAN party again. Experience the unparalleled speed and lower latency, and prioritize gaming traffic with QoS. Let’s begin the unprecedented smooth game!Ideal for Small and Home OfficeWork at office or home with lightning-fast connections to workstations, desktop computers, and WiFi 6 access points.2.5G Super-Fast Speedswithout Changing CablesFlawlessly integrated into existing gigabit Ethernet network infrastructures, 2.5× faster speeds* with regular Cat5e Ethernet cables, without the need to upgrade to Cat6 wiring, reducing wiring costs and hassle.Silent Operation withIndustry-Leading Fanless DesignThe revolutionary fanless design ensures unprecedented silent operation, ideal for any home or business. Durable metal casing, desktop/wall-mounting design and professional heat dissipation design are well-suited for different environments.Just Plug and Play for Internet AccessA plug-and-play design allows for easy deployment without the need for a technician. Auto MDI/MDIX eliminates the need for crossover cables.
| Management features | |
|---|---|
| Switch type | Unmanaged |
| Ports & interfaces | |
| Basic switching RJ-45 Ethernet ports quantity | 5 |
| Basic switching RJ-45 Ethernet ports type | 2.5G Ethernet (100/1000/2500) |
| 2.5G Ethernet (copper) ports quantity | 5 |
| Network | |
| Networking standards | IEEE 802.3,IEEE 802.3ab,IEEE 802.3p,IEEE 802.3u,IEEE 802.3x,IEEE 802.3z |
| 10G support | N |
| Auto MDI/MDI-X | Y |
| Ethernet LAN data rates | 10,100,1000 Mbit/s |
| Auto-negotiation | Y |
| Data transmission | |
| Switching capacity | 25 Gbit/s |
| Forwarding rate | 18.6 Mpps |
| MAC address table | 16000 entries |
| Store-and-forward | Y |
| Jumbo frames support | Y |
| Jumbo frames | 10000 |
| Packet buffer memory | 1.5 MB |
| Design | |
| Rack mounting | N |
| Product colour | Black |
| LED indicators | Y |
| Power | |
| Power source | DC |
| Power supply included | Y |
| Input current | 1 A |
| Input voltage | 12 V |
| Power consumption (max) | 12.11 W |
| Power over Ethernet (PoE) | |
| Power over Ethernet (PoE) | N |
| Operational conditions | |
| Operating temperature (T-T) | 0 - 40 °C |
| Storage temperature (T-T) | -40 - 70 °C |
| Operating relative humidity (H-H) | 10 - 90 % |
| Storage relative humidity (H-H) | 5 - 90 % |
| Heat dissipation | 41.32 BTU/h |
| Weight & dimensions | |
| Width | 209 mm |
| Depth | 126 mm |
| Height | 26 mm |
| Packaging content | |
| Cables included | LAN (RJ-45) |
| Quick start guide | Y |
| Packaging data | |
| Package width | 240 mm |
| Package depth | 315 mm |
| Package height | 70 mm |
| Package weight | 870 g |
| Certificates | |
| Certification | CE, FCC ,RoHS |
| Logistics data | |
| Harmonized System (HS) code | 85176990 |
