TP-Link TL-SG1005LP network switch Unmanaged Gigabit Ethernet (10/100/1000) Power over Ethernet (PoE) Black
TP-Link TL-SG1005LP network switch Unmanaged Gigabit Ethernet (10/100/1000) Power over Ethernet (PoE) Black
€37,09

TP-Link TL-SG1005LP, Unmanaged, Gigabit Ethernet (10/100/1000), Power over Ethernet (PoE), Wall mountable

Availability:: Arriving soon
EAN:6935364052720Categories:Networking

Professional 5-Port Gigabit Switch with 4 PoE+ PortsPlug and Play, with PoE power supply which meets the needs of diverse devices.Dedicated 4-Port PoE+ Switch (40 W Budget) for Numerous ApplicationsCompliance with the 802.3af/at PoE+ standard supports up to 30 W on each PoE port. The total 40 W PoE power budget for the 4× PoE ports opens up a wide range of applications, such as surveillance for offices, dormitories, and small businesses. It is fully compatible with IP cameras, access points, IP phones, computers, printers, and more.Intelligent Power ManagementWhen total power consumption exceeds 40 W, the intelligent power management will cut the lower priority port power. This ensures the high priority port’s power supply and protects the device from power overload. It also automatically detects and provides the required power for your PoE devices while protecting your PoE and non-PoE equipment from being damaged.Advanced Functions for Higher PerformanceAdministrators can designate the priority of traffic based on QoS, for example, to ensure that voice and video applications remain clear and lag-free.IGMP Snooping optimizes multimedia traffic delivery, to ensure a better network experience especially for applications like IPTV.Durable Metal CasingThe interior components of TL-SG1005LP are protected by high-quality metal casing to ensure a long product life. Having passed an array of stringent reliability tests, TL-SG1005LP delivers switching performance you can depend on.

Management features
Switch typeUnmanaged
Quality of Service (QoS) supportY
Ports & interfaces
Basic switching RJ-45 Ethernet ports quantity5
Basic switching RJ-45 Ethernet ports typeGigabit Ethernet (10/100/1000)
Gigabit Ethernet (copper) ports quantity5
Network
Networking standardsIEEE 802.1p,IEEE 802.3ab,IEEE 802.3af,IEEE 802.3at,IEEE 802.3i,IEEE 802.3u,IEEE 802.3x
10G supportN
Copper ethernet cabling technology10BASE-T,100BASE-TX,1000BASE-T
Cable types supportedCat3,Cat4,Cat5,Cat5e,Cat6
Flow control supportY
Auto MDI/MDI-XY
Auto-negotiationY
MAC address auto-learning supportedY
MAC address auto-aging supportedY
Data transmission
Switching capacity10 Gbit/s
Forwarding rate7.44 Mpps
MAC address table2000 entries
Store-and-forwardY
Jumbo frames supportY
Jumbo frames16000
Security
IGMP snoopingY
Design
Rack mountingN
StackableN
Product colourBlack
LED indicatorsY
Wall mountableY
Performance
Maximum cable length100 m
FanlessY
Power
Power sourceDC/PoE
Power supply includedY
AC input voltage100 - 240 V
AC input frequency50/60 Hz
DC input voltage53.5 V
Input current0.81 A
Power consumption (max)47.5 W
Power over Ethernet (PoE)
Power over Ethernet (PoE)Y
Power over Ethernet plus (PoE+) ports quantity4
Total Power over Ethernet (PoE) budget40 W
Operational conditions
Operating temperature (T-T)0 - 40 °C
Storage temperature (T-T)-40 - 70 °C
Operating relative humidity (H-H)10 - 90 %
Storage relative humidity (H-H)5 - 90 %
Heat dissipation161.98 BTU/h
Weight & dimensions
Width99.8 mm
Depth98 mm
Height25 mm
Packaging content
User guideY
Packaging data
Package typeBox
Package width131 mm
Package depth196 mm
Package height121 mm
Package weight730 g
Sustainability
Sustainability complianceY
Certificates
Compliance certificatesCE,Federal Communications Commission (FCC),RoHS
CertificationFCC, CE, RoHS
Logistics data
Harmonized System (HS) code85176990
