TP-Link RE505X network extender Network transmitter & receiver White 10, 100, 1000 Mbit/s
TP-Link RE505X, Network transmitter & receiver, 1200 Mbit/s, 10,100,1000 Mbit/s, Windows 10, Windows 10 Education, Windows 10 Education x64, Windows 10 Enterprise, Windows 10..., Internet Explorer 11, Firefox 12.0, Chrome 20.0, Safari 4.0, External
Availability: Arriving Soon
Expand Coverage of the Fastest Next-Gen Wi-FiAX1500 Range ExtenderCutting-Edge Wi-Fi 6The latest Wi-Fi technology eliminates annoying lag, endless loading, and dead spots. Enjoy the future of faster network loads and more connections.Fill Every Inch of Your Home with Wi-Fi 6The 505X wirelessly connects to your router, boosting your Wi-Fi 6 signal throughout your home so you can binge watch your favorite show anywhere.Dual Band, More BenefitsAdaptive Path SelectionKeeps your network running at top-speed by automatically choosing the fastest connection path to the router. High Speed ModeUse both Wi-Fi bands to enjoy super-fast connections —ideal for HD streaming and gaming.Built-In Access Point ModeRE505X is more than just a wireless range extender.Simply plug an Ethernet cable into its port to easily turn that wired connection into a high-speed dual band wireless signal.TP-Link OneMeshOneMesh is a simple way to form a Mesh network with a single Wi-Fi name for seamless whole-home coverage. Just connect a OneMesh range extender to a OneMesh router. No more searching around for a stable connection.Smart RoamingUninterrupted streaming when moving around your home One Wi-Fi NameNo more switching Wi-Fi network names Easy CreationOneMesh Router and OneMesh Range Extenders pair instantly Unified ManagementManage the entire network all from the TP-Link Tether appEnjoy an AX Mesh Network with Your Existing RouterWant a Mesh network? Hesitating whether you should replace your current router with a new Mesh set? Update your existing TP-Link router’s firmware to the OneMeshTM version—no need to replace anything. Connect the RE505X to the router. Enjoy your Mesh network.Control at Your FingertipsSet up and manage your Wi-Fi through the TP-Link Tether app from your smartphone (Android, iOS), including TP-Link routers and range extenders.
| Performance | |
|---|---|
| Type | Network transmitter & receiver |
| Data transfer rate | 1200 Mbit/s |
| Ethernet LAN data rates | 10,100,1000 Mbit/s |
| WPS push button | Y |
| Plug and Play | Y |
| Windows operating systems supported | Windows 10,Windows 10 Education,Windows 10 Education x64,Windows 10 Enterprise,Windows 10 Enterprise x64,Windows 10 Home,Windows 10 Home x64,Windows 10 IOT Core,Windows 10 IoT Enterprise,Windows 10 Pro,Windows 10 Pro x64,Windows 10 x64,Windows 2000,Windows 2000 Professional,Windows 7,Windows 7 Enterprise,Windows 7 Enterprise x64,Windows 7 Home Basic,Windows 7 Home Basic x64,Windows 7 Home Premium,Windows 7 Home Premium x64,Windows 7 Professional,Windows 7 Professional x64,Windows 7 Starter,Windows 7 Starter x64,Windows 7 Ultimate,Windows 7 Ultimate x64,Windows 7 x64,Windows 8,Windows 8 Enterprise,Windows 8 Enterprise x64,Windows 8 Pro,Windows 8 Pro x64,Windows 8 x64,Windows 8.1,Windows 8.1 Enterprise,Windows 8.1 Enterprise x64,Windows 8.1 Pro,Windows 8.1 Pro x64,Windows 8.1 x64,Windows 98SE,Windows Vista,Windows Vista Business,Windows Vista Business x64,Windows Vista Enterprise,Windows Vista Enterprise x64,Windows Vista Home Basic,Windows Vista Home Basic x64,Windows Vista Home Premium,Windows Vista Home Premium x64,Windows Vista Ultimate,Windows Vista Ultimate x64,Windows Vista x64,Windows XP,Windows XP Home,Windows XP Home x64,Windows XP Professional,Windows XP Professional x64 |
| Mac compatibility | Y |
| Mac operating systems supported | Y |
| Linux operating systems supported | Y |
| Browser supported | Internet Explorer 11, Firefox 12.0, Chrome 20.0, Safari 4.0 |
| Antenna | |
| Antennas quantity | 2 |
| Antenna type | External |
| Transmitting power (CE) | 2.4 GHz ≤20dBm, 5 GHz ≤30dBm dBm |
| Network | |
| Ethernet LAN interface type | Gigabit Ethernet |
| Cabling technology | 10/100/1000Base-T(X) |
| Networking standards | IEEE 802.11a,IEEE 802.11ac,IEEE 802.11ax,IEEE 802.11b,IEEE 802.11g,IEEE 802.11n |
| Wi-Fi | Y |
| Top Wi-Fi standard | Wi-Fi 6 (802.11ax) |
| Wi-Fi standards | 802.11a,802.11b,802.11g,Wi-Fi 4 (802.11n),Wi-Fi 5 (802.11ac),Wi-Fi 6 (802.11ax) |
| Wi-Fi data rate (max) | 1200 Mbit/s |
| Wi-Fi band | Dual-band (2.4 GHz / 5 GHz) |
| WLAN data transfer rates supported | 300 Mbit/s |
| Security algorithms | 64-bit WEP,128-bit WEP,WPA,WPA-PSK,WPA2,WPA2-PSK |
| Ports & interfaces | |
| Ethernet LAN (RJ-45) ports | 1 |
| Design | |
| Product colour | White |
| LED indicators | Power,WAN,WLAN |
| Quantity per pack | 1 pc(s) |
| Reset button | Y |
| Power | |
| AC input voltage | 100 - 240 V |
| AC input frequency | 50/60 Hz |
| Power consumption (max) | 10 W |
| Operational conditions | |
| Operating temperature (T-T) | 0 - 40 °C |
| Storage temperature (T-T) | -40 - 70 °C |
| Operating relative humidity (H-H) | 10 - 90 % |
| Storage relative humidity (H-H) | 5 - 90 % |
| Weight & dimensions | |
| Width | 74 mm |
| Depth | 46 mm |
| Height | 124.8 mm |
| Packaging content | |
| Quick start guide | Y |
| Packaging data | |
| Package type | Box |
| Package width | 202 mm |
| Package depth | 125 mm |
| Package height | 97 mm |
| Package weight | 400 g |
| Certificates | |
| Compliance certificates | RoHS |
| Logistics data | |
| Harmonized System (HS) code | 85176990 |
