Lindy 47483 networking cable Black 3 m Cat6a U/FTP (STP)
Lindy 47483, 3 m, Cat6a, U/FTP (STP), RJ-45, RJ-45, Black
Availability: Arriving Soon
Cat.6A U/FTP flat network cable with support for bandwidth up to 500MHz and features a snagless design with gold plated contacts for ethernet standards up to 10GBase-T.Cat.6A cable, for operating frequencies up to 500MHz, shielded with foil shielded with single pair shielding (U/FTP). Designed as flat ribbon cable for use in environments with restricted or limited installation space. These cables are manufactured and tested according to the ISO/IEC 11801 specification. The cables are packaged individually in a polybag.The gold-plated contacts ensure reliable, corrosion-free connections over extensive periods of time. A robust snagless strain relief design prevents damage to the connector latch during installation and removal.The very flexible and thin ribbon cable construction allows the cables to be installed in restricted or limited spaces.Available lengths: 0.3m, 1m, 2m, 3m, 5m, 10m.Available colours: Black, White.
| Features | |
|---|---|
| Product colour | Black |
| Cable length | 3 |
| Cable standard | Cat6a |
| Cable shielding | U/FTP (STP) |
| Connector 1 | RJ-45 |
| Connector 2 | RJ-45 |
| Connector 1 gender | Male connector |
| Connector 2 gender | Male connector |
| Connector contacts plating | Nickel/Gold |
| Connector shielding | Y |
| Connector shield material | Aluminium |
| Jacket material | Polyvinyl chloride (PVC) |
| Conductor material | Copper |
| Cabling technology | 10/100/1000Base-T(X) |
| AWG wire size | 32 |
| Frequency | 500 |
| Bend radius (min) | 60 |
| Operational conditions | |
| Operating temperature (T-T) | -10 - 60 |
| Storage temperature (T-T) | -10 - 40 |
| Certificates | |
| Certification | RoHS, REACH, California Proposition 65 |
| Weight & dimensions | |
| Connector 1 dimensions (WxDxH) | 11 x 28 x 6 |
| Connector 2 dimensions (WxDxH) | 11 x 28 x 6 |
| Packaging data | |
| Package type | Polybag |
| Logistics data | |
| Harmonized System (HS) code | 84733080 |
