Lanview LVO231230-FLEX InfiniBand/fibre optic cable 30 m LC LC/LC Aqua colour
€31,22
Lanview LVO231230-FLEX, 30 m, LC/LC, OM3, LC, LC
Availability: Arriving Soon
The Lanview Bendable series is engineered for flexible cable management, able to bend and sustain any angle from a straight line to 90 degrees. The boot, shaped around a single stainless-steel wire, is easily adjustable by hand, while the internal wire maintains the set angle or direction.The boot's design permits repositioning at any moment or straightening for the disconnection of connectors. Its versatility guarantees ideal connector positioning in demanding situations, like confined areas or environments with high density.
| Features | |
|---|---|
| Cable length | 30 m |
| Fibre optic type | OM3 |
| Cable shape | Round |
| Connector 1 | LC |
| Connector 2 | LC |
| Connector 1 gender | Male connector |
| Connector 2 gender | Male connector |
| Connector polish type | UPC |
| Cable type | LC/LC |
| Product colour | Aqua colour |
| Full duplex | Y |
| Core diameter | 50 µm |
| Cladding diameter | 125 µm |
| Fiber mode structure | Multi-mode |
| Wavelengths supported | 850,953,1260,1280,1300 nm |
| Insertion loss | 0.3 dB |
| Return loss | 35 dB |
| Compressive strength | 10 |
| Jacket material | Low smoke zero halogen (LSZH) |
| Plug and Play | Y |
| Sustainability | |
| Doesn't contain | Halogen |
| Certificates | |
| Compliance certificates | REACH,RoHS |
| Operational conditions | |
| Operating temperature (T-T) | -40 - 75 °C |
| Storage temperature (T-T) | -40 - 85 °C |
| Weight & dimensions | |
| Cable diameter | 2 mm |
| Weight | 550 g |
| Bending radius | 30 mm |
| Packaging data | |
| Package width | 250 mm |
| Package depth | 50 mm |
| Package height | 300 mm |
| Package weight | 550 g |
| Logistics data | |
| Warranty period | 25 year(s) |
