TP-Link Omada 8-Port 2.5G L2+ Managed Switch
(0 review)Add your review
€256,74

TP-Link Omada 8-Port 2.5G L2+ Managed Switch, Managed, L2+, 2.5G Ethernet (100/1000/2500), Rack mounting, 1U

Availability: Arriving Soon
EAN:4897098689523Categories:NetworkingTags:tp-link, network switches, tp, link, omada, 8, port

Ultrafast 2.5G Managed Switch with 10G Uplink for Futuristic NetworkSG3210X-M210G Lightning-FastUplink Connection2× 10 Gbps SFP+ Slots for High-Bandwidth Connectivity2.5G Portsfor WiFi 7/6E/68× 2.5 Gbps Ports Uplock the Full Potential of WiFi 7/6E/6 APsCentralized CloudManagementSDN Solutions Integration for a Highly Efficient NetworkAdvanced L2+FeaturesStatic Routing, IGMP Snooping, 802.1Q VLAN and MoreEnterprise Switchwith 10G Uplink2× 10 Gbps SFP+ slots provide non-blocking switching performance and ultra-low latency, so reliable and lightning-fast connections to server and other switches are easily built.Unlock the Highest Performance of 2.5G Multi-Gig Bandwidth and Devices8× 2.5-Gigabit ports unlock the highest performance of your Multi-Gig bandwidth and devices. Auto-negotiation speed connections sense the link speeds and intelligently adjust for compatibility and optimal performance for all your devices, including desktop, 4K video, 2.5G Wi-Fi 7/6E/6 APs, 2.5G NAS, 2.5G PCIe adapter, gaming console, VR gaming, and more.Software Defined Networking (SDN) with Cloud AccessOmada’s Software Defined Networking (SDN) platform integrates network devices, including access points, switches and gateways, providing 100% centralized cloud management. Omada creates a highly scalable network—all controlled from a single interface. Seamless wireless and wired connections are provided, ideal for use in hospitality, education, retail, offices, and more.Secure NetworkingSecurity features include IP-MAC-Port-VID Binding, Port Security, Storm Control and DHCP Snooping to defend against a range of network threats. An integrated list of common DoS attacks is available, making it easier than ever to prevent them. In addition, the Access Control Lists (ACL, L2 to L4) feature restricts access to sensitive network resources by denying packets based on source and destination MAC address, IP address, TCP/UDP ports or VLAN ID. Users’ network access can be controlled via 802.1X authentication, which works with a RADIUS/Tacacs+ server to grant access only when valid user credentials are provided.Enterprise Level FeaturesA complete lineup of L2+ features are supported, including 802.1Q VLAN, Port Mirroring, STP/RSTP/MSTP, Link Aggregation Control Protocol, and 802.3x Flow Control. Advanced IGMP Snooping ensures the switch intelligently forwards multicast streams to only the appropriate subscribers, cutting out unnecessary traffic, while IGMP throttling & filtering restrict each subscriber on a port level to prevent unauthorized multicast access. Static Routing is a simple way of segmenting the network and internally routs traffic through the switch for improved efficiency.Advanced QoSVoice and video traffic can be prioritized based on IP address, MAC address, TCP port number, UDP port number, and more. With QoS (Quality of Service), voice and video services remain smooth, even when bandwidth is in short supply.ISP FeaturesQinQ, L2PT PPPoE ID Insertion and IGMP authentication features are provided, developed with service providers in mind. 802.3ah OAM and Device Link Detection Protocol (DLDP) offer easy monitoring and troubleshooting of Ethernet links.IPv6 SupportIPv6 functions such as Dual IPv4/IPv6 Stack, MLD Snooping, IPv6 ACL, DHCPv6 Snooping, IPv6 Interface, Path Maximum Transmission Unit (PMTU) Discovery and IPv6 Neighbor Discover guarantee your network is ready for the Next Generation Network (NGN) without upgrading your hardware.

Management features
Switch typeManaged
Switch layerL2+
Quality of Service (QoS) supportY
Web-based managementY
Cloud-managedY
Traffic classificationY
ARP inspectionY
Configuring Location Settings (CLI)Y
System event logY
MIB supportRFC2925, RFC2618, RFC2620, RFC2021, RFC2819, RFC2674, RFC1493, RFC1643, RFC2233, RFC1213
Ports & interfaces
Basic switching RJ-45 Ethernet ports quantity8
Basic switching RJ-45 Ethernet ports type2.5G Ethernet (100/1000/2500)
2.5G Ethernet (copper) ports quantity8
SFP+ module slots quantity2
Console portRJ-45/micro-USB
Power connectorAC-in jack
Network
Networking standardsIEEE 802.1D,IEEE 802.1s,IEEE 802.1w
10G supportY
Port mirroringY
IP routingY
Flow control supportY
Link aggregationY
Broadcast storm controlY
Rate limitingY
Spanning tree protocolY
Head-of-line (HOL) blockingY
Ethernet LAN data rates100,1000,2500 Mbit/s
VLAN supportY
Virtual LAN featuresMAC address-based VLAN,Port-based VLAN,Private VLAN,Protocol-based VLAN,Tagged VLAN,Voice VLAN
Number of VLANs4000
Data transmission
Switching capacity80 Gbit/s
Forwarding rate59.52 Mpps
MAC address table16000 entries
Static routeY
Number of static routes48
Number of IP interfaces16
Jumbo frames supportY
Jumbo frames9000
Packet buffer memory12 MB
Security
DHCP featuresDHCP client,DHCP relay,DHCP server,DHCP snooping,DHCPv6 client,DHCPv6 snooping
Access Control List (ACL)Y
IGMP snoopingY
Security algorithmsHTTPS,SSH,SSH-2,SSL/TLS
MAC address filteringY
Static port securityY
SSH/SSL supportY
Loop protectionY
BPDU filtering/protectionY
IP-MAC-Port bindingY
AuthenticationMAC-based authentication,Port-based authentication
Password protectionY
Authentication typeAAA,TACACS+
Queue scheduling algorithmsSP,WRR+SP,Weighted Round Robin (WRR)
Multicast features
Multicast supportY
Multicast Listener Discovery (MLD) snoopingY
Protocols
Management protocolsSNMPv1/v2c/v3, SNTP
GARP VLAN Registration Protocol (GVRP)Y
Design
Rack mountingY
Form factor1U
Product colourBlack
LED indicatorsY
Number of fans2 fan(s)
Performance
FanlessY
Power
Power sourceAC
Power supply includedY
AC input voltage100 - 240 V
AC input frequency50/60 Hz
Power consumption (typical)15 W
Operational conditions
Operating temperature (T-T)0 - 50 °C
Storage temperature (T-T)-40 - 70 °C
Operating relative humidity (H-H)10 - 90 %
Storage relative humidity (H-H)5 - 90 %
Heat dissipation51.18 BTU/h
Weight & dimensions
Width294 mm
Depth180 mm
Height44 mm
Packaging content
Cables includedAC
Quick start guideY
Packaging data
Package typeBox
Package width528 mm
Package depth250 mm
Package height80 mm
Package weight2840 g
Certificates
CertificationCE, FCC, RoHS
Logistics data
Harmonized System (HS) code85176990
