StarTech.com 10/100 Mbps Single Mode Fiber Media Converter SC 30 km
StarTech.com 10/100 Mbps Single Mode Fiber Media Converter SC 30 km, 200 Mbit/s, 10Base-T, 100Base-FX, Fast Ethernet, 10,100 Mbit/s, Full, Half
Availability: Arriving Soon
Convert and extend a 10/100 Mbps Ethernet connection up to 18.6 miles/30km over Single Mode SC fiberThe ET90110SM302 10/100 Mbps Single Mode Fiber Media Converter SC (30 km) lets you extend a Fast Ethernet network (10/100) over single mode fiber, at distances up to 30 km (18.6 miles).A cost-effective solution for connecting a 10/100 Mbps Ethernet (10/100Base-T) network to remote network segments over a 100Base-FX fiber backbone, the media converter is designed to offer a durable and convenient Ethernet to fiber solution, with an all-steel chassis, and simple plug-and-play installation with minimal configuration required.For added versatility, this fiber media converter supports standalone operation, or installation into the 20 Slot, 2U Rackmount Chassis (ETCHS2U).Backed by a StarTech.com 2-year warranty and free lifetime technical support.The StarTech.com Advantage- Link loss forwarding, remote monitoring of status ensures maximum up-time- Provides Ethernet to Fiber conversion as a standalone device, or can be installed into the ETCHS2U 20 slot chassis for added versatility- Rugged steel casing for durability in harsh environments
| Network | |
|---|---|
| Maximum data transfer rate | 200 |
| Converter input interface | 10Base-T |
| Converter output interface | 100Base-FX |
| Ethernet interface type | Fast Ethernet |
| Ethernet LAN data rates | 10,100 |
| Auto MDI/MDI-X | Y |
| Duplex system | Full,Half |
| Performance | |
| Maximum transfer distance | 30000 |
| Wavelength | 1310 |
| Fiber mode structure | Single-mode |
| Features | |
| Internal | N |
| Plug and Play | Y |
| Product colour | Black |
| Ports & interfaces | |
| Connectivity technology | Wired |
| Ethernet LAN (RJ-45) ports | 1 |
| Fiber ports quantity | 1 |
| Fiber optic connector | SC |
| DC-in jack | Y |
| Power | |
| Output voltage | 12 |
| Output current | 1 |
| External power adapter | Y |
| Weight & dimensions | |
| Weight | 600 |
| Operational conditions | |
| Operating temperature (T-T) | 0 - 60 |
| Storage temperature (T-T) | -10 - 70 |
| Operating relative humidity (H-H) | 10 - 90 |
| Packaging content | |
| Manual | Y |
| Packaging data | |
| Package width | 206 |
| Package depth | 137 |
| Package height | 89 |
| Package weight | 766 |
| Certificates | |
| Compliance certificates | RoHS |
| Certification | CE, FCC |
| Logistics data | |
| Harmonized System (HS) code | 85176990 |
| Other features | |
| Dimensions (WxDxH) | 95 x 160 x 20 |
| Full duplex | Y |
