iiyama TF5539AS-B1AG Signage Display Digital signage flat panel 138.7 cm (54.6") LED 500 cd/m² 4K Ultra HD Black Touchscreen Built-in processor Android 24/7
iiyama TF5539AS-B1AG, Digital signage flat panel, 138.7 cm (54.6"), LED, 3840 x 2160 pixels, 24/7
Availability:: Arriving soon
Enjoy an all-in-one interactive display that combines the best in PCAP Touchscreen technology, offering the versatility and freedom of Android OS, easily customized to your needs by installing applications directly to it. Offering a powerful, yet flexible user experience, fostering creative communication with the benefits of a secure and controllable Touchscreen. The refined edge-to-edge glass design of the TF5539AS-B1AG lends itself for integration into a large variety of environments where polished design and functionality are needed, like Huddle spaces in the modern office space, Retail shops and Kiosks. The on-board iiSignage² CMS (Content Management System) gives you total control of your messaging and advertising, remotely and safely. The EShare App enables you to bring effortless ideation and efficient collaboration in your enterprise or school. You can start sharing wireless easier than ever before. For ease of integration, the TF5539AS-B1AG can be equipped with optional external mounting brackets ( OMK4-2 ).
| Display | |
|---|---|
| Panel type | IPS |
| LED backlight | Y |
| Display diagonal | 54.6 " |
| Display technology | LED |
| Display resolution | 3840 x 2160 pixels |
| Display brightness | 500 cd/m² |
| HD type | 4K Ultra HD |
| Touchscreen | Y |
| Touchscreen technology | Projected capacitive system |
| Number of simultaneous touchpoints | 40 |
| Multi-touch | Y |
| Native aspect ratio | 16:9 |
| Response time | 8 ms |
| Contrast ratio (typical) | 1200:1 |
| Viewing angle, horizontal | 178 ° |
| Viewing angle, vertical | 178 ° |
| Display number of colours | 1.07 billion colours |
| Pixel pitch | 0.315 x 0.315 mm |
| Active display area (W x H) | 1209.6 x 680.4 mm |
| Display diagonal (metric) | 139 cm |
| Horizontal scan range | 28 - 160 kHz |
| Native refresh rate | 60 Hz |
| Haze rate | 25 % |
| Surface hardness | 7H |
| Glass thickness | 4 mm |
| Ports & interfaces | |
| HDMI ports quantity | 2 |
| HDMI version | 2.0 |
| DVI port | N |
| DisplayPorts quantity | 1 |
| DisplayPort version | 1.2 |
| USB port | Y |
| USB ports quantity | 3 |
| USB connector type | USB Type-A,USB Type-B |
| USB 2.0 Type-B ports quantity | 1 |
| Ethernet LAN (RJ-45) ports | 1 |
| RS-232C | Y |
| Audio | |
| Built-in speaker(s) | Y |
| Number of built-in speakers | 2 |
| RMS rated power | 20 W |
| Design | |
| Product design | Digital signage flat panel |
| Placement supported | Indoor |
| Orientation | Horizontal/Vertical |
| Product colour | Black |
| Screen shape | Flat screen |
| VESA mounting | Y |
| Panel mounting interface | 400 x 400 mm |
| Bezel width (bottom) | 30 mm |
| Bezel width (side) | 30 mm |
| Bezel width (top) | 30 mm |
| Anti-glare screen | Y |
| Performance | |
| Purpose | Universal |
| On Screen Display (OSD) | Y |
| Number of OSD languages | 13 |
| On Screen Display (OSD) languages | CZE,DAN,DEU,DUT,ENG,ESP,FIN,FRE,ITA,POL,RUS,SLV |
| Operating hours (hours/days) | 24/7 |
| HDCP | Y |
| International Protection (IP) code | IP65 |
| HDCP version | 2.2 |
| Mean time between failures (MTBF) | 50000 h |
| Power | |
| Power consumption (typical) | 139 W |
| Power consumption (standby) | 0.4 W |
| Power consumption (off) | 0.3 W |
| Energy efficiency class (SDR) | F |
| Energy efficiency class (HDR) | Not available |
| Energy consumption (SDR) per 1000 hours | 78 kWh |
| AC input voltage | 100 - 240 V |
| AC input frequency | 50/60 Hz |
| Energy efficiency scale | A to G |
| Computer system | |
| Computer system | Y |
| Built-in processor | Y |
| Processor manufacturer | ARM |
| Processor architecture | ARM Cortex-A53+Cortex-A73 |
| Internal memory | 4 GB |
| Internal storage capacity | 32 GB |
| Operating system installed | Android |
| Operating system version | 11 |
| Weight & dimensions | |
| Display width | 1274 mm |
| Display depth | 65.2 mm |
| Display height | 744.8 mm |
| Display weight | 39600 g |
| Width (with stand) | 1274 mm |
| Depth (with stand) | 65.2 mm |
| Height (with stand) | 744.8 mm |
| Weight (with stand) | 39600 g |
| Packaging data | |
| Package width | 1428 mm |
| Package depth | 1428 mm |
| Package height | 894 mm |
| Package volume | 47200 cm³ |
| Package weight | 47200 g |
| Packaging content | |
| Remote control included | Y |
| Batteries included | Y |
| Cables included | AC,DisplayPort,HDMI,USB |
| Operational conditions | |
| Operating temperature (T-T) | 0 - 40 °C |
| Storage temperature (T-T) | -20 - 60 °C |
| Certificates | |
| Certification | TCO Certified, CB, TÜV-Bauart, EAC, RoHS support, ErP, WEEE, REACH |
| Network | |
| Ethernet LAN | Y |
| Other features | |
| Maximum refresh rate | 60 Hz |
| Quick start guide | Y |
| Viewable size, horizontal | 1209.6 mm |
| Viewable size, vertical | 680.4 mm |
| Display surface | Matt |
| Power supply type | Internal |
