TP-Link 16-Port 10/100Mbps + 2-Port Gigabit Unmanaged PoE Switch

€223,67

TP-Link 16-Port 10/100Mbps + 2-Port Gigabit Unmanaged PoE Switch, Unmanaged, Fast Ethernet (10/100), Power over Ethernet (PoE), Rack mounting

Availability:: Arriving soon

Add to Cart

Add to wishlist

Compare

EAN:6935364099824Categories:Networking

Easy to Use PoE Switch with Innovative DesignUp To 250m Data and Power Transmission for SurveillanceHigh PoE Power BudgetTL-SL1218MP complies with the 802.3af/at PoE+ standard, supporting up to 30W power supply on each PoE port. The total high PoE power budget of up to 192W for the 16 PoE ports, making it ideal for small to medium business surveillance systems.Up to 250m Transmission for SurveillanceTL-SL1218MP is a special designed PoE switch for IP surveillance applications. PoE switch makes surveillance installation simpler, safer and less expensive. With the extend mode, the PoE transmission distance reaches up to 250m* which makes it perfect for IP Camera deployment in large area coverage.Video Quality GuaranteedPriority mode guarantees the important data, such as video surveillance, delivered with the best priority passing the data fabric even when the traffic load is heavy. Hardware switch for easy configuration with no login required.

Management features
Switch type	Unmanaged
Ports & interfaces
Basic switching RJ-45 Ethernet ports quantity	16
Basic switching RJ-45 Ethernet ports type	Fast Ethernet (10/100)
Fast Ethernet (copper) ports quantity	16
Gigabit Ethernet (copper) ports quantity	2
Combo SFP ports quantity	2
Network
Networking standards	IEEE 802.3af,IEEE 802.3at
10G support	N
Copper ethernet cabling technology	10BASE-T,100BASE-TX,1000BASE-T
Flow control support	Y
Auto MDI/MDI-X	Y
Data transmission
Switching capacity	7.2 Gbit/s
MAC address table	8000 entries
Store-and-forward	Y
Jumbo frames support	Y
Jumbo frames	10000
Packet buffer memory	4.1 MB
Security
MAC address filtering	Y
Design
Rack mounting	Y
Stackable	N
Product colour	Black
LED indicators	LAN,PoE,Status
Number of fans	2 fan(s)
Power
Power source	AC
Power supply included	Y
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (typical)	18.7 W
Power over Ethernet (PoE)
Power over Ethernet (PoE)	Y
Power over Ethernet plus (PoE+) ports quantity	16
Total Power over Ethernet (PoE) budget	192 W
Operational conditions
Operating temperature (T-T)	0 - 40 °C
Storage temperature (T-T)	-40 - 70 °C
Operating relative humidity (H-H)	10 - 90 %
Storage relative humidity (H-H)	5 - 90 %
Heat dissipation	741.15 BTU/h
Weight & dimensions
Width	440 mm
Depth	180 mm
Height	44 mm
Packaging content
Cables included	LAN (RJ-45)
Quick start guide	Y
User guide	Y
Manual	Y
Logistics data
Harmonized System (HS) code	85176990
