iiyama TF1015MC-B3 computer monitor 25.6 cm (10.1") 1280 x 800 pixels HD LED Touchscreen Black

(0 review)Add your review

€317,99

iiyama TF1015MC-B3, 25.6 cm (10.1"), 1280 x 800 pixels, HD, LED, 29 ms, Black

Availability:: Arriving soon

Add to Cart

Add to wishlist

Compare

EAN:4948570124107Categories:Monitors & Projectors

The ProLite TF1015MC (10.1 inch) uses PCAP touch technology and is built into an eye catching bezel with edge-to-edge glass. Thanks to a glass overlay covering the screen and a rugged bezel, it guarantees high durability and scratch-resistance, making it perfect for kiosk and high use public facing applications. The IPS panel technology offers accurate and consistent colour reproduction with wide viewing angles. Equipped with a foam seal finish it supports seamless integration into kiosks and provides IP65 rating resulting in dust and water resistance from the front. Landscape, portrait and face-up orientation ensures flexible mounting possibilities in almost any installation. For ease of integration, the TF1015MC can be equipped with optional external mounting brackets ( OMK2-1 ) making it an ideal solution for kiosk integrators, industrial environments, control rooms and interactive multimedia.

Display
Display diagonal	10.1 "
Display resolution	1280 x 800 pixels
HD type	HD
Native aspect ratio	16:10
Display technology	LED
Panel type	IPS
Touchscreen	Y
Touchscreen technology	Projected capacitive system
Touch technology	Multi-touch
Number of simultaneous touchpoints	10
Display brightness (peak)	500 cd/m²
Display brightness (typical)	500 cd/m²
Display brightness	500 cd/m²
Response time	29 ms
Screen shape	Flat screen
Contrast ratio (typical)	800:1
Maximum refresh rate	75 Hz
Viewing angle, horizontal	178 °
Viewing angle, vertical	178 °
Display number of colours	16.7 million colours
Pixel pitch	0.1695 x 0.1695 mm
Horizontal scan range	30 - 49.7 kHz
Viewable size, horizontal	216.96 mm
Viewable size, vertical	135.6 mm
Digital horizontal frequency	30 - 49.7 kHz
Display diagonal (metric)	25.7 cm
Surface hardness	7H
Performance
NVIDIA G-SYNC	N
AMD FreeSync	N
Design
Market positioning	Business
Product colour	Black
Front bezel colour	Black
Glass thickness	3.3 mm
Ports & interfaces
Built-in USB hub	Y
Number of upstream ports	1
USB Touch port	Y
VGA (D-Sub) ports quantity	1
DVI port	N
HDMI	Y
HDMI ports quantity	1
DisplayPorts quantity	1
HDCP	Y
Network
Ethernet LAN	Y
Ergonomics
VESA mounting	Y
Panel mounting interface	100 x 100 mm
Wall mountable	Y
On Screen Display (OSD)	Y
On Screen Display (OSD) languages	CHI (SIMPL),DEU,ENG,ESP,FRE,ITA,JPN
Number of OSD languages	7
Plug and Play	Y
LED indicators	Y
Power
Energy efficiency class (SDR)	C
Energy efficiency class (HDR)	Not available
Energy consumption (SDR) per 1000 hours	6 kWh
Power consumption (typical)	6 W
Power consumption (standby)	0.7 W
Power consumption (off)	0.3 W
AC adapter output voltage	12 V
Power supply type	External
Energy efficiency scale	A to G
European Product Registry for Energy Labelling (EPREL) code	378636
Operational conditions
Operating temperature (T-T)	0 - 40 °C
Storage temperature (T-T)	-20 - 60 °C
Weight & dimensions
Width (with stand)	260.5 mm
Depth (with stand)	39.5 mm
Height (with stand)	183.5 mm
Weight (with stand)	1400 g
Width (without stand)	260.5 mm
Depth (without stand)	39.5 mm
Height (without stand)	183.5 mm
Weight (without stand)	2700 g
Packaging data
Package width	310 mm
Package depth	310 mm
Package height	160 mm
Package weight	2700 g
Packaging content
Cables included	AC,DisplayPort,HDMI,USB
Remote control included	Y
Quick start guide	Y
Other features
International Protection (IP) code	IP65
Placement supported	Indoor
Audio out (mini jack)	1
Active display area (W x H)	216.96 x 135.6 mm
USB ports quantity	1
Mean time between failures (MTBF)	50000 h
Ethernet LAN (RJ-45) ports	1
Certification	CB, CE, TÜV-Bauart, EAC, cULus
