TP-Link Omada DS105G-M2 network switch Unmanaged 2.5G Ethernet (100/1000/2500) Black

€78,83

TP-Link Omada DS105G-M2, Unmanaged, 2.5G Ethernet (100/1000/2500)

EAN:4895252507508Categories:Networking

TP-Link Omada DS105G-M2 network switch Unmanaged 2.5G Ethernet (100/1000/2500) Black. No further description available.

Management features
Switch type	Unmanaged
Quality of Service (QoS) support	Y
Ports & interfaces
Basic switching RJ-45 Ethernet ports quantity	5
Basic switching RJ-45 Ethernet ports type	2.5G Ethernet (100/1000/2500)
Power connector	DC-in jack
Network
Networking standards	IEEE 802.1p,IEEE 802.3ab,IEEE 802.3bz,IEEE 802.3u,IEEE 802.3x
10G support	N
Copper ethernet cabling technology	2.5GBASE-T,100BASE-TX,1000BASE-T
Flow control support	Y
Auto MDI/MDI-X	Y
Ethernet LAN data rates	10,100,1000,2500 Mbit/s
Auto-negotiation	Y
Data transmission
Switching capacity	25 Gbit/s
Forwarding rate	18.6 Mpps
MAC address table	4000 entries
Store-and-forward	Y
Jumbo frames support	Y
Jumbo frames	12
Packet buffer memory	8 MB
Security
IGMP snooping	Y
Design
Rack mounting	N
Product colour	Black
Housing material	Metal
Reset button	Y
LED indicators	Activity,Link,Power
Performance
Fanless	Y
Power
Power source	DC
Power supply included	Y
DC input voltage	9 V
Input current	0.6 A
Power consumption (max)	5.81 W
Power over Ethernet (PoE)
Power over Ethernet (PoE)	N
Operational conditions
Operating temperature (T-T)	0 - 40 °C
Storage temperature (T-T)	-40 - 70 °C
Operating relative humidity (H-H)	10 - 90 %
Storage relative humidity (H-H)	5 - 90 %
Heat dissipation	19.759 BTU/h
Weight & dimensions
Width	99.8 mm
Depth	98 mm
Height	25 mm
Packaging content
Cables included	Power
User guide	Y
Packaging data
Rubber feet	Y
Certificates
Compliance certificates	CE,Federal Communications Commission (FCC),Industry Canada (IC),RoHS
