Philips E-Line 86BDL3152E Digital signage flat panel 2.18 m (86") 350 cd/m² 4K Ultra HD Black Touchscreen Built-in processor Android 16/7

(0 review)Add your review

€2353,17

Philips E-Line 86BDL3152E, Digital signage flat panel, 2.18 m (86"), 3840 x 2160 pixels, 16/7

Availability:: Arriving soon

Add to Cart

Add to wishlist

Compare

EAN:8712581806088Categories:Display & Signage

Interactive education displayFeaturing multi-touch technologyThis interactive display maximises engagement and inspires collaboration with up to 40 touchpoints. Powered by Android 13 and with toughened anti-glare and anti-reflection glass, it’s made to withstand heavy daily use in busy environments.

Display
Panel type	ADS
Display diagonal	86 "
Display resolution	3840 x 2160 pixels
Display brightness	350 cd/m²
HD type	4K Ultra HD
Touchscreen	Y
Touchscreen technology	Infrared
Number of simultaneous touchpoints	40
Multi-touch	Y
Native aspect ratio	16:9
Response time	8 ms
Contrast ratio (typical)	1200:1
Viewing angle, horizontal	178 °
Viewing angle, vertical	178 °
Display number of colours	1.07 billion colours
Pixel pitch	0.4935 x 0.4935 mm
Display diagonal (metric)	218.44 cm
Ports & interfaces
HDMI ports quantity	2
HDMI version	2.0
DVI port	N
VGA (D-Sub) input ports	1
USB port	Y
USB ports quantity	8
USB connector type	USB Type-A,USB Type-C
USB 2.0 Type-B ports quantity	3
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	4
USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity	1
USB Power Delivery (USB PD)	Y
USB Power Delivery up to	65 W
Ethernet LAN (RJ-45) ports	2
RS-232C	Y
Remote (IR) input	1
Remote (IR) output	1
Card reader integrated	Y
Compatible memory cards	MicroSD (TransFlash)
OPS module slot	Y
Audio
Built-in speaker(s)	Y
Number of built-in speakers	2
RMS rated power	32 W
Design
Product design	Digital signage flat panel
Orientation	Horizontal/Vertical
Product colour	Black
Screen shape	Flat screen
VESA mounting	Y
Panel mounting interface	800 x 600 mm
Performance
Purpose	Universal
On Screen Display (OSD)	Y
On Screen Display (OSD) languages	ARA,CHI (SIMPL),CHI (TR),DAN,DEU,DUT,ENG,ESP,FIN,FRE,ITA,JPN,NOR,POL,POR,RUS,SWE,TUR
Operating hours (hours/days)	16/7
Mean time between failures (MTBF)	50000 h
Power
Power consumption (standby)	0.5 W
Energy efficiency class (SDR)	G
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Computer system
Computer system	Y
Computer system type	System on Chip (SoC)
Built-in processor	Y
Processor model	A55
Internal memory	4 GB
On-board graphics card model	ARM Mali-G52
Internal storage capacity	32 GB
Operating system installed	Android
Operating system version	13
Video formats supported	H.263,H.264,H.265,MPEG1,MPEG2,MPEG4,VP9
Audio formats supported	AAC,HE-AAC,MPEG
Image formats supported	BMP,JPEG,PNG
Weight & dimensions
Display width	1957 mm
Display depth	100 mm
Display height	1160 mm
Packaging data
Package weight	44700 g
Packaging content
Remote control included	Y
Batteries included	Y
Stylus pen	Y
Number of stylus pens	1
Cables included	AC,DVI,HDMI,IR sensor,RS-232,USB
Operational conditions
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	10 - 90 %
Storage temperature (T-T)	-20 - 60 °C
Storage relative humidity (H-H)	10 - 90 %
Certificates
Certification	CE, FCC, Class A, RoHS, CB, EAC, EMF, ETL
Network
Ethernet LAN	Y
Technical details
Display resolution at frequency	720 x 400 70Hz 832 x 624 75Hz 1440 x 900 60Hz 1600 x 900 60Hz 1680 x 1050 60Hz 1920 x 1080 60Hz 1024 x 768 60Hz 1152 x 870 75Hz 1280 x 1024 60Hz 1280 x 720 60Hz 3840 x 2160 30, 60Hz 640 x 480 60,67,75Hz 800 x 600 60Hz
