TP-Link Omada ER703WP-4G-Outdoor gateway/controller 10, 100, 1000 Mbit/s
TP-Link Omada ER703WP-4G-Outdoor, White, Wall mounting, Status, External, 4 dBi, 512 MB
Availability:: Arriving soon
All-in-one DeviceCombines 4G Internet access, Wi-Fi 6 wireless technology and 3 Gigabit PoE in/out ports all in one device, and automatic back up and load balancing between 4G and wired WAN can be reached. Enjoyed a powerful and versatile gateway with easy deployment.Specially Designed Weatherproof Enclosure for OutdoorsRated as IP55 during Ingress Protection testing, a resilient weatherproof enclosure protects the gateway against harsh outdoor conditions.Multiple Power Supply OptionsPowered by PoE or DC (compatible with solar panels) to overcome mains access limitations.Plug and PlayInsert a Nano SIM card or connect to an Ethernet WAN Port to get gigabit Wi-Fi. Enjoy hassle-free connect to surveillance cameras via cable or wireless.Centralized ManagementEnables to easy network setup across multiple sites without sending engineer for on-site configuration. Remotely manage via Omada app or web, offering the Essentials version of cloud services for free, reducing maintenance costs for MSP/SI.Easy InstallationEasy to mount to a wall or pole with the provided mounting kits. Its compact design allows you to place the gateway flexibly.
| Design | |
|---|---|
| Product colour | White |
| Mounting type | Wall mounting |
| LED indicators | Status |
| Features | |
| Antenna type | External |
| Antenna gain level (max) | 4 dBi |
| Antennas quantity | 2 |
| Short Message Service (SMS) | Y |
| Performance | |
| Control display unit | N |
| Internal memory | 512 MB |
| Internal memory type | DDR4 |
| Flash memory | 256 MB |
| Protocols | |
| DHCP server | Y |
| Network | |
| Ethernet LAN data rates | 10,100,1000 Mbit/s |
| Forwarding rate | 1453489 Mpps |
| Networking standards | IEEE 802.3at,IEEE 802.3bt |
| Wi-Fi | Y |
| Mobile network generation | 4G |
| Data network | LTE |
| Downlink/uplink speed | 300/50 Mbit/s |
| GSM bands supported | 850,900,1800,2100 MHz |
| Frequency band | 2.4/5 GHz |
| All services ready time | 3.8 s |
| SSL VPN throughput | 0.0866 Gbit/s |
| PPTP/L2TP VPN tunnels (max) | 50 |
| SSL VPN tunnels (max) | 50 |
| Security | |
| MAC address filtering | Y |
| Security algorithms | SSID,WPA2,WPA3 |
| Ports & interfaces | |
| SIM card slot | Y |
| SIM card type | NanoSIM |
| DC-in jack | Y |
| Management features | |
| Web-based management | Y |
| Power | |
| Power consumption (max) | 16.6 W |
| Power over Ethernet (PoE) | Y |
| Weight & dimensions | |
| Width | 174 mm |
| Depth | 100.4 mm |
| Height | 38.7 mm |
| Operational conditions | |
| Operating temperature (T-T) | -30 - 60 °C |
| Storage temperature (T-T) | -40 - 70 °C |
| Operating relative humidity (H-H) | 5 - 95 % |
| Storage relative humidity (H-H) | 5 - 90 % |
| Certificates | |
| Certification | CE, FCC, RoHS |
