LG 86BH5F-M Signage Display Digital signage flat panel 2.18 m (86") Wi-Fi 500 cd/m² Black WebOS 24/7
LG 86BH5F-M, Digital signage flat panel, 2.18 m (86"), 3840 x 600 pixels, Wi-Fi, 24/7
Availability:: Arriving soon
58:9 Space-Fitting Wide ScreenThe 86BH5F is the most suitable display for delivering new forms of advertising and multiplexed information in a 58:9 widescreen format. It can bring unused & leftover space to life by being installed without restriction.58:9 Extended Wide FormatIt is a unique wide screen with 58:9 bar type which provides much more flexibility in playing content* than the conventional display of 16:9 ratio.Ultra HD Resolution (3,840 x 600)Ultra HD resolution delivers an immersive viewing experience with vivid colors and clear images.Multi Screen Mode with 4PBPThe Picture-by-Picture (PBP) feature allows you to show multi content in one single display by up-to four parts. It is very useful and convenient to deliver various advertisements or pieces of information at the same time without calibration.Tiled Scene with Immersive ViewThe 86BH5F can show a tiled scene by up to 15 × 15 configuration. This will be the best choice if you want to use a large screen, or provide visual impact to your customers in a different way.IP5x Certified DesignThe IP5x Dust-Proof Certification ensures that the product is completely protected from dust, eliminating the risk of performance degradation.User-Friendly UXThe 86BH5F is equipped with a user-friendly UX to simplify approach flows, groups similar functions together, and adopts an intuitive GUI for ease of use. When using the display in portrait mode, OSD* can also be adjusted accordingly.LAN Daisy Chain ManagementBy using this daisy-chained network feature, you can execute commands such as controlling, monitoring and even updating firmware.Real-Time Monitoring with LG ConnectedCareEasier and faster maintenance are available with our optional cloud service solution LG ConnectedCare*. It remotely manages the status of displays in client workplaces for fault diagnosis and remote-control services, ensuring the stable operation of clients' businesses.
| Display | |
|---|---|
| Panel type | IPS |
| Display diagonal | 86 " |
| Display resolution | 3840 x 600 pixels |
| Display brightness | 500 cd/m² |
| Touchscreen | N |
| Response time | 8 ms |
| Contrast ratio (typical) | 1100:1 |
| Contrast ratio (dynamic) | 500000:1 |
| Viewing angle, horizontal | 178 ° |
| Viewing angle, vertical | 178 ° |
| Display number of colours | 1.07 billion colours |
| Haze rate | 3 % |
| RGB colour space | NTSC |
| Ports & interfaces | |
| HDMI ports quantity | 3 |
| HDMI version | 2.2 |
| DVI port | Y |
| DVI-D ports quantity | 1 |
| DisplayPorts quantity | 2 |
| DisplayPorts in | 1 |
| DisplayPorts out | 1 |
| USB port | Y |
| USB ports quantity | 2 |
| USB version | 2.0 |
| Ethernet LAN (RJ-45) ports | 1 |
| Audio (L/R) in | 1 |
| Audio (L/R) out | 1 |
| RS-232C | Y |
| Remote (IR) input | 1 |
| Audio | |
| Built-in speaker(s) | N |
| Design | |
| Product design | Digital signage flat panel |
| Placement supported | Indoor |
| Orientation | Horizontal/Vertical |
| Product colour | Black |
| VESA mounting | Y |
| Panel mounting interface | 600 x 200 mm |
| Bezel width (bottom) | 5.9 mm |
| Bezel width (side) | 4.4 mm |
| Bezel width (top) | 5.9 mm |
| Performance | |
| Purpose | Retail |
| Operating hours (hours/days) | 24/7 |
| Power | |
| Power consumption (typical) | 220 W |
| Energy efficiency class (SDR) | G |
| Energy consumption (SDR) per 1000 hours | 143 kWh |
| AC input voltage | 100 - 240 V |
| AC input frequency | 50 - 60 Hz |
| Heat dissipation | 751 BTU/h |
| Energy efficiency scale | A to G |
| Computer system | |
| Computer system | Y |
| Internal memory | 8 GB |
| Operating system installed | WebOS |
| Weight & dimensions | |
| Width | 2158.3 mm |
| Depth | 81.7 mm |
| Height | 348.5 mm |
| Weight | 20500 g |
| Packaging content | |
| Remote control included | Y |
| Cables included | AC,DisplayPort,IR,IR sensor |
| Operational conditions | |
| Operating temperature (T-T) | 0 - 40 °C |
| Operating relative humidity (H-H) | 10 - 80 % |
| Logistics data | |
| Harmonized System (HS) code | 85285210 |
| Network | |
| Ethernet LAN | Y |
| Wi-Fi | Y |
| Technical details | |
| Special features | CB, NRTL, FCC Class "A", CE, KC, |
| Sustainability certificates | ErP |
