TP-Link 5-Port 10/100Mbps Desktop PoE Switch with 4-Port

€28,41

TP-Link 5-Port 10/100Mbps Desktop PoE Switch with 4-Port, Unmanaged, Fast Ethernet (10/100), Full duplex, Power over Ethernet (PoE)

Availability: In Stock

Add to Cart

Add to wishlist

Compare

EAN:6935364083199Categories:NetworkingTags:tp-link, network switches, tp, link, 5, port, 10

PoE Switches for Your Ultra Convenience5-Port 10/100Mbps Desktop Switch with 4-Port PoEPower over Ethernet4 of the 5 Auto-Negotiation RJ45 ports (Port 1 to Port 4) of the switch support Power over Ethernet (PoE) function. These PoE ports can automatically detect and supply power with those IEEE 802.3af compliant Powered Devices (PDs).Intelligent Power ManagementWhen total power consumption excels 58W, the intelligent power management will cut the lower priority port power off to ensure the high priority port’s power supply and protect the device from power overload operation.Sturdy Metal CasingSturdy, compact metal casing and shielded RJ45 ports, with desktop/wall-mounting design, to meet your needs in any environment. Besides, fanless design ensures quiet operation.

Management features
Switch type	Unmanaged
Ports & interfaces
Basic switching RJ-45 Ethernet ports quantity	5
Basic switching RJ-45 Ethernet ports type	Fast Ethernet (10/100)
Network
Networking standards	IEEE 802.3af,IEEE 802.3x
10G support	N
Copper ethernet cabling technology	10BASE-T,100BASE-TX,100BASE-T
Cable types supported	Cat3,Cat4,Cat5,Cat5e,Cat6
Full duplex	Y
Half duplex	Y
Flow control support	Y
Auto MDI/MDI-X	Y
Auto-negotiation	Y
MAC address auto-learning supported	Y
MAC address auto-aging supported	Y
Data transmission
Switching capacity	1 Gbit/s
Forwarding rate	0.744 Mpps
MAC address table	2000 entries
Store-and-forward	Y
Jumbo frames support	Y
Jumbo frames	2000
Design
Rack mounting	N
Stackable	N
Product colour	Black
LED indicators	Y
Performance
Maximum cable length	100 m
Fanless	Y
Power
Power source	DC/PoE
Power supply included	N
AC input voltage	220 V
AC input frequency	50 Hz
DC input voltage	53.5 V
Input current	1.31 A
Power consumption (max)	74 W
Power over Ethernet (PoE)
Power over Ethernet (PoE)	Y
Power over Ethernet plus (PoE+) ports quantity	4
Total Power over Ethernet (PoE) budget	67 W
Operational conditions
Operating temperature (T-T)	0 - 40 °C
Storage temperature (T-T)	-40 - 70 °C
Operating relative humidity (H-H)	10 - 90 %
Storage relative humidity (H-H)	5 - 90 %
Heat dissipation	252.34 BTU/h
Weight & dimensions
Width	99.8 mm
Depth	98 mm
Height	25 mm
Packaging content
User guide	Y
Packaging data
AC adapter included	Y
Package type	Box
Package width	131 mm
Package depth	196 mm
Package height	121 mm
Package weight	760 g
Sustainability
Sustainability compliance	Y
Certificates
Compliance certificates	CE,Federal Communications Commission (FCC),RoHS
Logistics data
Harmonized System (HS) code	85176990
