Allied Telesis AT-x230-18GP-50 Managed L2+ Gigabit Ethernet (10/100/1000) Power over Ethernet (PoE) Grey

€1277,02

Allied Telesis AT-x230-18GP-50, Managed, L2+, Gigabit Ethernet (10/100/1000), Full duplex, Power over Ethernet (PoE), Rack mounting

Availability: Arriving Soon

Add to Cart

Add to wishlist

Compare

EAN:0767035202662Categories:NetworkingTags:

The Allied Telesis x230-18GP features 16 x 10/100/1000T PoE+ ports with 2 SFP Gigabit uplink ports. A full feature-set with Power over Ethernet Plus (PoE+) makes it ideal for applications at the network edge, supporting the growth of wireless networking and digital video surveillance.

Management features
Switch type	Managed
Switch layer	L2+
Quality of Service (QoS) support	Y
Web-based management	Y
System event log	Y
MIB support	RFC1212, RFC1213, RFC1227, RFC1239, RFC2011, RFC2012, RFC2013, RFC2096, RFC2819, RFC2863, RFC3418, RFC3621, RFC3636
Ports & interfaces
Basic switching RJ-45 Ethernet ports quantity	16
Basic switching RJ-45 Ethernet ports type	Gigabit Ethernet (10/100/1000)
SFP module slots quantity	2
Console port	RJ-45
Power connector	DC-in jack
Network
Networking standards	IEEE 802.2,IEEE 802.3,IEEE 802.3ab,IEEE 802.3ad,IEEE 802.3af,IEEE 802.3at,IEEE 802.3az,IEEE 802.3u,IEEE 802.3x,IEEE 802.3z
10G support	N
Copper ethernet cabling technology	1000BASE-T,100BASE-T,10BASE-T
Port mirroring	Y
Full duplex	Y
Flow control support	Y
Link aggregation	Y
Broadcast storm control	Y
Auto MDI/MDI-X	Y
Spanning tree protocol	Y
VLAN support	Y
Data transmission
Switching capacity	36.6
Throughput	26.8
MAC address table	16000
Jumbo frames support	Y
Packet buffer memory	1.5
Security
DHCP features	DHCPv6 client,DHCP client
IGMP snooping	Y
Security algorithms	EAP-TTLS,MD5,PEAP,SSL/TLS
Multicast features
Multicast support	Y
Protocols
Management protocols	IGMP, MLD, Telnet, SMTP, NTP
Supported network protocols	SNTP
Design
Rack mounting	Y
Product colour	Grey
LED indicators	Y
Safety	UL60950-1, CAN/CSA-C22.2 No. 60950-1-03, EN60950-1, EN60825-1, AS/NZS 60950.1
Performance
Internal memory	256
Flash memory	64
Power
AC input voltage	100 - 240
AC input frequency	50 - 60
Power consumption (max)	21
Power over Ethernet (PoE)
Power over Ethernet (PoE)	Y
Power over Ethernet (PoE) ports quantity	16
Power over Ethernet plus (PoE+) ports quantity	8
Total Power over Ethernet (PoE) budget	296
Operational conditions
Operating temperature (T-T)	0 - 50
Storage temperature (T-T)	-20 - 70
Operating relative humidity (H-H)	5 - 90
Storage relative humidity (H-H)	5 - 95
Non-operating altitude	0 - 3048
Heat dissipation	168
Weight & dimensions
Width	341
Depth	231
Height	44
Weight	3000
Packaging data
Package weight	4200
Certificates
Certification	UL, cUL, UL-EU
Logistics data
Harmonized System (HS) code	85176990
