iiyama TE7512MIS-B3AG Signage Display Kiosk design 190.5 cm (75") LCD Wi-Fi 400 cd/m² 4K Ultra HD Black Touchscreen Built-in processor Android 11 24/7
iiyama TE7512MIS-B3AG, Kiosk design, 190.5 cm (75"), LCD, 3840 x 2160 pixels, Wi-Fi, 24/7
Availability:: Arriving soon
The TE7512MIS-B3AG is an exceptional 4K UHD interactive display designed by iiyama to enhance collaboration, communication, and engagement. With key features like Zero Airgap LCD screen eliminating parallax, accurate PureTouch-IR, iiWare 10 with Android 11, Wifi, and the iiyama DMS (Device management System), this display transforms the way you engage with content, making it an indispensable tool for modern workspaces and educational settings. Boasting a new 4K Interface with User Profiles for simple login and access to your very own bespoke application and Cloud Drives or harmonize with your existing estate and unleash the true power of Windows and Office applications. iiyama TE7512MIS-B3AG becomes a highly personalised & flexible device within a busy hybrid environment for multiple users. Share wirelessly more easily than ever before with iiyama Share and EShare app, bringing effortless ideation and efficient collaboration in your enterprise or school. This affordable display transforms the modern workplaces, educational institutions, dynamic meeting spaces and beyond. Elevate your interactive experience with the iiyama TE12 SERIES displays and embrace the future of visual communication.
| Display | |
|---|---|
| Panel type | IPS |
| Display diagonal | 75 " |
| Display technology | LCD |
| Display resolution | 3840 x 2160 pixels |
| Display brightness | 400 cd/m² |
| HD type | 4K Ultra HD |
| Touchscreen | Y |
| Touchscreen technology | PureTouch-IR |
| Number of simultaneous touchpoints | 40 |
| Native aspect ratio | 16:9 |
| Response time | 8 ms |
| Contrast ratio (typical) | 1200:1 |
| Contrast ratio (dynamic) | 4000:1 |
| Viewing angle, horizontal | 178 ° |
| Viewing angle, vertical | 178 ° |
| Display number of colours | 1.07 billion colours |
| Pixel pitch | 0.4296 x 0.4296 mm |
| Active display area (W x H) | 1650 x 928 mm |
| Display diagonal (metric) | 189.3 cm |
| Horizontal scan range | 30 - 135 kHz |
| Native refresh rate | 60 Hz |
| Surface hardness | 7H |
| Glass thickness | 3 mm |
| Glass film | AG/AR Film |
| Ports & interfaces | |
| HDMI ports quantity | 4 |
| HDMI version | 2.0 |
| HDMI input ports quantity | 1 |
| HDMI output ports quantity | 1 |
| DVI port | N |
| VGA (D-Sub) input ports | 1 |
| USB port | Y |
| USB ports quantity | 5 |
| USB version | 3.2 Gen 1 (3.1 Gen 1) |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity | 2 |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity | 3 |
| USB Power Delivery (USB PD) | Y |
| USB Power Delivery up to | 65 W |
| Ethernet LAN (RJ-45) ports | 1 |
| RS-232 interface | Y |
| RS-232C | Y |
| Remote (IR) input | 1 |
| Audio Return Channel (ARC) | Y |
| Audio | |
| Built-in speaker(s) | Y |
| Number of built-in speakers | 2 |
| RMS rated power | 32 W |
| Design | |
| Product design | Kiosk design |
| Placement supported | Indoor |
| Orientation | Horizontal |
| Product colour | Black |
| VESA mounting | Y |
| Panel mounting interface | 800 x 400 mm |
| Bezel width (bottom) | 45 mm |
| Bezel width (side) | 16.5 mm |
| Bezel width (top) | 16.5 mm |
| Bezel colour | Black |
| Anti-glare screen | Y |
| Performance | |
| Purpose | Commercial |
| On Screen Display (OSD) | Y |
| On Screen Display (OSD) languages | CZE,DAN,DEU,ENG,ESP,FIN,FRE,ITA,POL,RUS,SLV |
| Operating hours (hours/days) | 24/7 |
| HDCP | Y |
| HDCP version | 2.2 |
| Mean time between failures (MTBF) | 50000 h |
| Power | |
| Power consumption (typical) | 125 W |
| Power consumption (standby) | 0.5 W |
| Power consumption (off) | 0.3 W |
| Energy efficiency class (SDR) | G |
| Energy efficiency class (HDR) | Not available |
| AC input voltage | 100 - 240 V |
| AC input frequency | 50/60 Hz |
| Computer system | |
| Computer system | N |
| Built-in processor | Y |
| Processor manufacturer | ARM |
| Processor family | ARM Cortex |
| Processor model | A55 |
| Processor architecture | ARM Cortex-A55 |
| Processor cores | 4 |
| Internal memory | 8 GB |
| On-board graphics card model | ARM Mali-G52 |
| Internal storage capacity | 64 GB |
| Operating system installed | Android 11 |
| Weight & dimensions | |
| Display width | 1709.5 mm |
| Display depth | 88 mm |
| Display height | 1020 mm |
| Display weight | 47300 g |
| Width (with stand) | 1709.5 mm |
| Depth (with stand) | 88 mm |
| Height (with stand) | 1020 mm |
| Weight (with stand) | 47300 g |
| Packaging data | |
| Package width | 1863 mm |
| Package depth | 1863 mm |
| Package height | 1140 mm |
| Package volume | 60600 cm³ |
| Package weight | 60600 g |
| Packaging content | |
| Remote control included | Y |
| Batteries included | Y |
| Cables included | HDMI,Power,USB |
| Wi-Fi module included | Y |
| Operational conditions | |
| Operating temperature (T-T) | 0 - 40 °C |
| Operating relative humidity (H-H) | -20 - 60 % |
| Certificates | |
| Certification | CB, CE, TÜV-Bauart, EAC, RoHS support, ErP, WEEE, REACH, EPA 8.0 |
| Network | |
| Ethernet LAN | Y |
| Ethernet LAN data rates | 1000 Mbit/s |
| Wi-Fi | Y |
| Wi-Fi standards | 802.11a,802.11b,802.11g,Wi-Fi 4 (802.11n),Wi-Fi 5 (802.11ac),Wi-Fi 6 (802.11ax) |
| Other features | |
| Quick start guide | Y |
| Power supply type | Internal |
