FSP Vita power supply unit 750 W 20+4 pin ATX ATX Black
(0 review)Add your review
€84,59

FSP Vita, 750 W, 100 - 240 V, 50/60 Hz, 10-5 A, Active, 100 W

Availability: Arriving Soon
EAN:4711498480354Categories:PowerTags:fsp, power supply units, vita, power, supply, unit

The Future is Now:ATX 3.1 ReadyFollowing the latest ATX 3.1 regulation, this series supports 200% power excursion and ensure peak performance with future hardware upgrades.+5V & 3.3V DC to DC Circuit DesignIncrease the efficiency and stabilize the output voltage to ensure system stability.Powerful Single +12V RailModern CPUs and graphics cards can draw significant amounts of power, especially during peak loads., a single +12V rail PSU offers a good balance of simplicity, power delivery capability, and stability.Premium, Black Flat CablesFeaturing improved black, flat cables that are soft and easy to bend, users can manage them more easily, saving time and creating more space for optimal cooling performance in your PC build.105˚C Japanese Bulk CapacitorThe bulk capacitor inside serves to support working under an extremely harsh environment, such as with high temperatures, peak voltage fluctuations. It stabilizes the performance for high reliability that your system can count on.Compact PSU size:140 x 150 x 86mm140mm in length which is relatively shorter than industry standard, it’s ideal for compact PC or space-constraint environment without compromising on performance.

Power
Total power750
AC input voltage100 - 240
AC input frequency50/60
Input current10-5
Power Factor Correction (PFC) typeActive
Combined power (+3.3V)100
Combined power (+12V)750
Combined power (+5V)100
Combined power (-12V)3.6
Combined power (+5Vsb)15
Max output current (+3.3V)20
Max output current (+12V)62.5
Max output current (+5V)20
Max output current (-12V)0.3
Max output current (+5Vsb)3
Efficiency90
Power protection featuresOver current,Over power,Over voltage,Overheating,Short circuit,Under voltage
Ports & interfaces
Motherboard power connector20+4 pin ATX
Motherboard power cable length600
Number of SATA power connectors8
SATA power cable length500
Peripheral (Molex) power connectors (4-pin)4
PCI Express power connectors (6+2 pin)4
CPU power connector (4+4 pin)Y
CPU power cable length700
Cabling typeNon-Modular
Performance
80 PLUS certification80 PLUS Gold
PurposePC
Power supply unit (PSU) form factorATX
ATX version3.1
EPS version2.92
Bearing technologyHYB
Design
Product colourBlack
Cooling typeActive
Fan diameter120
Number of fans1
Fan locationTop
Packaging content
Cables includedCPU,Peripheral (Molex),SATA
Weight & dimensions
Width150
Depth140
Height86
