Allied Telesis GS950/28PS Managed Gigabit Ethernet (10/100/1000) Power over Ethernet (PoE) Grey

(0 review)Add your review

€627,06

Allied Telesis GS950/28PS, Managed, Gigabit Ethernet (10/100/1000), Power over Ethernet (PoE), Rack mounting

Availability: Arriving Soon

Add to Cart

Add to wishlist

Compare

EAN:767035208725Categories:NetworkingTags:

The Allied Telesis GS950/28PS eco-friendly WebSmart switch upholds the Allied Telesis commitment to environmentally friendly processes and products. It is designed to minimize power consumption through the use of a high-efficiency power supply and a low power chipset.The Allied Telesis GS950/28PS Gigabit Ethernet WebSmart switch features 24 10/100/1000T ports and four SFP ports, delivering up to 30 Watts per port (PoE+) to support video surveillance and security cameras, wireless access points, IP phones and other PoE powered devices. The PoE option eliminates the need for power rewiring and minimizes the clutter of power supplies and adapters in awkward places. Thanks to its compact size, the GS950/28PS is the ideal cost-effective solution for small businesses, classrooms, larger retail stores, healthcare clinics and spas.

Management features
Switch type	Managed
Quality of Service (QoS) support	Y
Web-based management	Y
System event log	Y
MIB support	Y
Ports & interfaces
Basic switching RJ-45 Ethernet ports quantity	24
Basic switching RJ-45 Ethernet ports type	Gigabit Ethernet (10/100/1000)
SFP module slots quantity	4
Fiber optic connector	FX,SX
Network
Networking standards	IEEE 802.1D,IEEE 802.1Q,IEEE 802.1p,IEEE 802.1s,IEEE 802.1w,IEEE 802.1x,IEEE 802.3,IEEE 802.3ab,IEEE 802.3ad,IEEE 802.3af,IEEE 802.3at,IEEE 802.3az,IEEE 802.3i,IEEE 802.3u,IEEE 802.3x,IEEE 802.3z
10G support	N
Copper ethernet cabling technology	10BASE-T,100BASE-T,1000BASE-T
Port mirroring	Y
IP routing	Y
Flow control support	Y
Link aggregation	Y
Broadcast storm control	Y
Rate limiting	Y
Spanning tree protocol	Y
Head-of-line (HOL) blocking	Y
VLAN support	Y
Virtual LAN features	Private VLAN,Tagged VLAN,Protocol-based VLAN,Port-based VLAN
Number of VLANs	256
Optical fiber
Fiber ethernet cabling technology	100BASE-FX,1000BASE-SX,1000BASE‑LX
Data transmission
Switching capacity	56 Gbit/s
Throughput	41.65 Mpps
MAC address table	8000 entries
Number of queues	4
Number of static routes	256
Jumbo frames support	Y
Jumbo frames	10000
Packet forwarding rate (1 Gbps)	1488000 pps
Packet forwarding rate (100 Mbps)	148800 pps
Packet forwarding rate (10 Mbps)	14880 pps
Packet buffer memory	1 MB
Security
DHCP features	DHCP client
Access Control List (ACL)	Y
Access Control List (ACL) rules	240
IGMP snooping	Y
Security algorithms	SNMP,SSL/TLS
MAC address filtering	Y
SSH/SSL support	Y
Multicast features
Multicast support	Y
Protocols
Supported network protocols	HTTP
Design
Rack mounting	Y
Product colour	Grey
Reset button	Y
Performance
Memory type	DRAM
Internal memory	64 MB
Flash memory	16 MB
Firmware upgradeable	Y
Power
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (max)	28.6 W
Power plug type	Type C
Power over Ethernet (PoE)
Power over Ethernet (PoE)	Y
Power over Ethernet (PoE) ports quantity	24
Power over Ethernet plus (PoE+) ports quantity	24
Power over Ethernet (PoE) power per port	30 W
Total Power over Ethernet (PoE) budget	185 W
Operational conditions
Operating temperature (T-T)	0 - 45 °C
Storage temperature (T-T)	-25 - 70 °C
Operating relative humidity (H-H)	5 - 90 %
Storage relative humidity (H-H)	5 - 95 %
Heat dissipation	97.59 BTU/h
Weight & dimensions
Width	450 mm
Depth	250 mm
Height	44 mm
Weight	3600 g
Packaging content
Cables included	AC
Quick start guide	Y
Manual	Y
Packaging data
Mounting brackets included	Y
Rubber feet	Y
Resource CD	Y
Certificates
Certification	IEC 68-2-36 IEC 68-2-29 IEC 68-2-32 UL94V-0 RoHS WEEE UL60950-1 2nd edition (UL) FCC/EN55022/CISPR 22 Class A VCCI Class A C-Tick EN60950 (TUV) EN55024 CE Mark CSA / CUL
