Allied Telesis AT-UMC2000/LC-901 network media converter 1000 Mbit/s 850 nm Multi-mode Grey

€390,08

Allied Telesis AT-UMC2000/LC-901, 1000 Mbit/s, 1000Base-SX, IEEE 802.1Q, IEEE 802.1p, Gigabit Ethernet, 1000 Mbit/s, 500 m

Availability:: Arriving soon

Add to Cart

Add to wishlist

Compare

EAN:767035210674Categories:Networking

The Allied Telesis UMC2000/LC Gigabit mini media converter is small and flexible, with a multi-mode LC fiber connector to convert USB (-A or -C) to 1000SX/LC. It is also TAA compliant.

Network
Maximum data transfer rate	1000 Mbit/s
Converter output interface	1000Base-SX
Networking standards	IEEE 802.1Q,IEEE 802.1p
Ethernet interface type	Gigabit Ethernet
Data transfer rate	1000 Mbit/s
Jumbo frames support	Y
VLAN support	Y
Performance
Maximum transfer distance	500 m
Wavelength	850 nm
Fiber mode structure	Multi-mode
Fiber cable diameters supported (core/cladding)	50/125,62.5/125 µm
Tx power (min)	-9.5 dBmW
Tx power (max)	-4 dBmW
Rx power (min)	-17 dBmW
Features
Internal	N
LED indicators	Y
Product colour	Grey
Ports & interfaces
Connectivity technology	Wired
Fiber optic connector	LC
Weight & dimensions
Width	54.9 mm
Depth	101.6 mm
Height	21.8 mm
Weight	170 g
Operational conditions
Operating temperature (T-T)	0 - 50 °C
Storage temperature (T-T)	-30 - 70 °C
Operating relative humidity (H-H)	5 - 95 %
Storage relative humidity (H-H)	5 - 95 %
Operating altitude	0 - 3048 m
