D-Link DMS-1250-12TP/E network switch Managed 2.5G Ethernet (100/1000/2500) Power over Ethernet (PoE) Black
D-Link DMS-1250-12TP/E, Managed, 2.5G Ethernet (100/1000/2500), Power over Ethernet (PoE), Rack mounting
Availability: Arriving Soon
2.5G Speed, Ready for Wi-Fi 6 and MoreThe DMS-1250 Series switches can enhance your network by connecting a Wi-Fi 6 Access Point to any of the 2.5 Gbps ports, effectively maximizing throughput and speed. Multi-Gigabit Ethernet eliminates potential bottlenecks with Wi-Fi 6 Access Points, enabling your network to fully leverage the efficiency and high speeds offered by Wi-Fi 6.Cutting-Edge PoE Features Ensuring Reliable Power DeliveryPoE+ ports provide a high power budget to fulfill the most business needs.The innovative PoE functions can ensure uninterrupted power delivery to the power devices.Intelligent Fan Control with Quiet OperationThe DMS-1250 PoE models with built-in internal fans which can automatically work between 5 levels of cooling to prevent the device from overheating or manually set to OFF or Quiet mode according to environment or operation temperature.6 kV Surge Protection for All Ethernet PortsThe DMS-1250 Series switches offer enhanced 6kV surge protection on all 2.5-Gigabit Ethernet access ports, ensuring that your network remains resilient and that your devices stay safe from electrical surges.Easy Management by DNC & D-View 8The DMS-1250 Series switches offers a range of management tools to cater to users' diverse needs. D-Link Nuclias Controller (DNC) and D-Link Nuclias Hub (DNH) enable the discovery and management of multiple D-Link devices, providing access to configure settings efficiently. Furthermore, the DMS-1250 Series can be seamlessly managed through D-View 8, a comprehensive central network management system. SNMP functionality allows for centralized network asset management, remote configuration, and logging functions.Best Choice for SOHO, SMB and MDUThe DMS-1250 Series switches are versatile, suitable for SOHO, SMB, and MDU environments. They provide high-speed data transmission with 2.5GE and a crucial 10G speed uplink for external connectivity. This high-speed uplink ensures that the entire MDU can access external services without encountering data bottlenecks. Furthermore, they effectively implement IEEE 802.3at or IEEE 802.3bt in DMS-1250-10SP, 10SPL, and 12TP to enable devices to connect and receive power supply.
| Management features | |
|---|---|
| Switch type | Managed |
| Quality of Service (QoS) support | Y |
| Web-based management | Y |
| ARP inspection | Y |
| MIB support | Y |
| Ports & interfaces | |
| Basic switching RJ-45 Ethernet ports quantity | 10 |
| Basic switching RJ-45 Ethernet ports type | 2.5G Ethernet (100/1000/2500) |
| 2.5G Ethernet (copper) ports quantity | 8 |
| 10G Ethernet (copper) ports quantity | 2 |
| Combo SFP ports quantity | 2 |
| Power connector | AC-in jack |
| Network | |
| Networking standards | IEEE 802.3ab,IEEE 802.3ae,IEEE 802.3af,IEEE 802.3an,IEEE 802.3at,IEEE 802.3az,IEEE 802.3bt,IEEE 802.3bz,IEEE 802.3u,IEEE 802.3z |
| 10G support | Y |
| Port mirroring | Y |
| Flow control support | Y |
| Broadcast storm control | Y |
| Spanning tree protocol | Y |
| Ethernet LAN data rates | 100,1000,2500 |
| VLAN support | Y |
| Number of VLANs | 4094 |
| Data transmission | |
| Switching capacity | 129 |
| Forwarding rate | 89.29 |
| MAC address table | 16000 |
| Store-and-forward | Y |
| Jumbo frames support | Y |
| Jumbo frames | 12000 |
| Security | |
| DHCP features | DHCP client,DHCP server,DHCP snooping |
| Access Control List (ACL) | Y |
| Access Control List (ACL) IPv4 entries | 768 |
| Access Control List (ACL) IPv6 entries | 384 |
| IGMP snooping | Y |
| IGMP entries | 256 |
| Loop protection | Y |
| Password protection | Y |
| Authentication type | RADIUS |
| Design | |
| Rack mounting | Y |
| Product colour | Black |
| Reset button | Y |
| LED indicators | Y |
| Performance | |
| Memory type | DRAM |
| Internal memory | 512 |
| Power | |
| Power source | AC |
| Power supply included | Y |
| AC input voltage | 100 - 240 |
| AC input frequency | 50/60 |
| Power consumption (max) | 289.74 |
| Power over Ethernet (PoE) | |
| Power over Ethernet (PoE) | Y |
| Power over Ethernet (PoE) ports quantity | 8 |
| Power over Ethernet (PoE) power per port | 30 |
| Total Power over Ethernet (PoE) budget | 240 |
| Operational conditions | |
| Operating temperature (T-T) | -5 - 50 |
| Storage temperature (T-T) | -20 - 70 |
| Operating relative humidity (H-H) | 0 - 95 |
| Storage relative humidity (H-H) | 0 - 95 |
| Weight & dimensions | |
| Width | 440 |
| Depth | 210 |
| Height | 44 |
| Weight | 3240 |
| Packaging content | |
| Quick start guide | Y |
| Certificates | |
| Certification | CB, UL, BSMI, CE Class A, VCCI Class A, FCC Class A, IC, BSMI, RCM |
