ATEN 1-Local/Remote Share Access Single Port 4K DisplayPort KVM over IP Switch
€1043,79
ATEN 1-Local/Remote Share Access Single Port 4K DisplayPort KVM over IP Switch, 4096 x 2160 pixels, Ethernet LAN, 4K Ultra HD, 9.76 W, Black
Availability: Arriving Soon
1x CN9950 4K DisplayPort KVM over IP Switch 1x DisplayPort cable 1x USB cable (USB-A to USB-B) 1x USB cable (USB-A to Mini-USB)1x power adapter 1x control terminal block 1x mounting kit 1x foot pad set 1x user instructions
| Ports & interfaces | |
|---|---|
| Keyboard port type | USB |
| Mouse port type | USB |
| Video port type | DisplayPort |
| DisplayPorts quantity | 2 |
| USB 2.0 Type-B ports quantity | 1 |
| Console ports | 3.5mm headphone,3.5mm mic,DisplayPort,USB A |
| Console USB ports quantity | 2 |
| USB connector type | Mini-USB B |
| PS/2 ports quantity | 1 |
| Serial port type | RJ-45 |
| Serial ports quantity | 2 |
| Audio connections | Y |
| Headphone outputs | 2 |
| Number of microphone inputs | 2 |
| DC-in jack | Y |
| Network | |
| Ethernet LAN | Y |
| Ethernet LAN (RJ-45) ports | 2 |
| Performance | |
| HD type | 4K Ultra HD |
| Maximum resolution | 4096 x 2160 pixels |
| Video bandwidth | 30 Hz |
| Design | |
| Product colour | Black |
| Housing material | Metal |
| LED indicators | Y |
| Display | |
| Built-in display | N |
| Power | |
| Power source | DC |
| Input voltage | 5 V |
| Power consumption (typical) | 9.76 W |
| Operational conditions | |
| Operating temperature (T-T) | 0 - 50 °C |
| Storage temperature (T-T) | -20 - 60 °C |
| Operating relative humidity (H-H) | 0 - 80 % |
| Weight & dimensions | |
| Width | 149.3 mm |
| Depth | 200 mm |
| Height | 28.5 mm |
| Weight | 1250 g |
| Packaging data | |
| Package width | 98 mm |
| Package depth | 325 mm |
| Package height | 210 mm |
| Package weight | 1670 g |
| Packaging content | |
| Cables included | DisplayPort,USB,USB Type-A to USB Type-B |
| Manual | Y |
| AC adapter included | Y |
| Logistics data | |
| Master (outer) case net weight | 6250 g |
| Harmonized System (HS) code | 85176200 |
| Master (outer) case width | 342 mm |
| Master (outer) case length | 512 mm |
| Master (outer) case height | 232 mm |
| Master (outer) case gross weight | 8980 g |
| Products per master (outer) case | 5 pc(s) |
