TP-Link AV1000 Gigabit Powerline ac Wi-Fi Kit
TP-Link AV1000 Gigabit Powerline ac Wi-Fi Kit, 1000 Mbit/s, IEEE 1901, IEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.3, IEEE..., Type E, Gigabit Ethernet, 10,100,1000 Mbit/s, Wi-Fi 5 (802.11ac)
Availability: Arriving Soon
Extend AC750 Wi-Fi to Every Room Using Existing Electrical SystemAV1000 Gigabit Powerline ac Wi-Fi KitExtend Wired and Wireless Network Using Electrical SystemTL-WPA7517 KIT transforms your home’s existing electrical circuit into a Gigabit network, and brings wired and wireless network to anywhere there is a power outlet.- > No need for drilling or wire installation- > Network passes through walls and floors- > Expand coverage by adding more extenders- > Powerline adapters must be deployed in sets of two or more and be connected to the same electrical circuitAV1000 Speeds and 300 Meters RangeUsing advanced HomePlug AV2 technology, TL-WPA7517 KIT ensures stable and high-speed Wi-Fi and wired connection, providing data transmissions of up to 1000 Mbps* over the electrical wiring for ranges up to 300 meters. Stream in HD, game online and download large files without interruption thanks to reliable powerline links.AC750 Wi-Fi for an Advanced Online ExperienceWith the 802.11ac Wi-Fi technology, the TL-WPA7517 operates a dual band Wi-Fi network (simultaneous 300 Mbps on 2.4 GHz and 433 Mbps on 5 GHz) with more bandwidth and less interference, maximizing the performance of your powerline network.One Tap for a Unified NetworkOne-Touch Wi-Fi ConfigurationInstantly copies your network name and password from your router for easy setup.Gigabit Ethernet for Fast Wired ConnectionsOne Gigabit Ethernet port provides reliable high-speed wired connection for a bandwidth intensive device, such as game consoles, smart TVs, STB and more, or connects multiple devices by adding a switch. Two Ethernet cables are included in the box.Powerline Management on Your SmartphoneManage your powerline Wi-Fi through tpPLC app from your smartphone (Android, iOS), or download new tpPLC Utility on PCs to manage the powerline network.- View real-time powerline speed- LED control (also controlled by LED On/Off button)- Guest network
| Performance | |
|---|---|
| Maximum data transfer rate | 1000 Mbit/s |
| Ethernet LAN | Y |
| Ethernet LAN interface type | Gigabit Ethernet |
| Ethernet LAN data rates | 10,100,1000 Mbit/s |
| Ethernet LAN (RJ-45) ports | 2 |
| Wi-Fi | Y |
| Top Wi-Fi standard | Wi-Fi 5 (802.11ac) |
| Wi-Fi standards | 802.11a,802.11b,802.11g,Wi-Fi 4 (802.11n),Wi-Fi 5 (802.11ac) |
| Wi-Fi band | Dual-band (2.4 GHz / 5 GHz) |
| WLAN data transfer rates supported | 300,433 Mbit/s |
| Networking standards | IEEE 1901,IEEE 802.11a,IEEE 802.11ac,IEEE 802.11b,IEEE 802.11g,IEEE 802.11n,IEEE 802.3,IEEE 802.3u |
| Power plug | Type E |
| Built-in power socket | N |
| PowerLine standard | HomePlug AV2 |
| Modulation | OFDM |
| Security algorithms | WEP,WPA-PSK,WPA2-PSK |
| Maximum operating distance | 300 m |
| Encryption button | Y |
| Plug and Play | Y |
| Power | |
| Power consumption (typical) | 6.5 W |
| Design | |
| Antenna type | Internal |
| LED indicators | LAN,PLC,Power,Wi-Fi |
| Product colour | White |
| Certification | CE, RoHS |
| System requirements | |
| Windows operating systems supported | Windows 10,Windows 7,Windows 8,Windows 8.1 |
| Linux operating systems supported | Y |
| Mac compatibility | Y |
| Mac operating systems supported | Y |
| Operational conditions | |
| Operating temperature (T-T) | 0 - 40 °C |
| Operating relative humidity (H-H) | 10 - 90 % |
| Weight & dimensions | |
| Width | 69.5 mm |
| Depth | 35 mm |
| Height | 124.1 mm |
| Packaging data | |
| Package width | 230 mm |
| Package depth | 190 mm |
| Package height | 100 mm |
| Package weight | 560 g |
| Packaging content | |
| Quick installation guide | Y |
| Cables included | LAN (RJ-45) |
| Logistics data | |
| Harmonized System (HS) code | 85171800 |
