ATEN VE2812EUT AV extender AV transmitter White
ATEN VE2812EUT AV extender AV transmitter White
€310,87

ATEN VE2812EUT, 4096 x 2160 pixels, AV transmitter, 150 m, Wired, White, HDCP

Availability:: In stock
EAN:4719264647383Categories:AV EquipmentTags:aten, av extenders, ve2812eut, av, extender

ATEN VE2812EUT is a transmitter for sending VGA (with audio) and HDMI signals up to 100 m over a single Cat 5e/6/6a or ATEN 2L-2910 Cat 6 cable. With EU Wall Plate design, the VE2812EUT can be conveniently mounted in a two-gang junction box. The VE2812EUT guarantees reliable transmission of HDMI / VGA signals. For HDMI signal transmission, it supports 3D, Deep Color, and embedded HD lossless audio formats. To pursue longer distance transmission, it supports Long Reach Mode up to 150 m via a single Cat 5e/6 cable at resolutions up to 1080p.For utility flexibility, the VE2812EUT can serve as a video switch by connecting two sources and distribute them to an identical output. The compact wall plate design does away with bulky cables, allowing a neat and convenient installation. Therefore, The VE2812EUT is specifically designed for use in meeting rooms, digital educational environment or wherever needed to meet application requirements.Note: Optional accessory (2X-050G) is available with a separate purchase if you wish to mount the VE2812EUT into the cable cubby.

Features
TypeAV transmitter
Maximum resolution4096 x 2160 pixels
Cable types supportedCat5e,Cat6,Cat6a
Maximum transfer distance150 m
Maximum refresh rate60 Hz
Supported graphics resolutions1600 x 1200 (UXGA),1920 x 1080 (HD 1080),3840 x 2160,4096 x 2160
Bandwidth340 MHz
HDCPY
MaterialMetal
Wall mountableY
Impedance100 Ω
Product colourWhite
Ports & interfaces
Connectivity technologyWired
Ethernet LANY
VGA (D-Sub) input ports1
HDMI in1
RS-232 input ports1
VGA (D-Sub) ports quantity1
Audio (L/R) out1
AUX inY
3.5 mm (1/8-inch) inY
Power
Power consumption (transmitter) (max)3.14 W
Operational conditions
Operating temperature (T-T)0 - 40 °C
Storage temperature (T-T)-20 - 60 °C
Operating relative humidity (H-H)0 - 80 %
Weight & dimensions
Width108 mm
Depth50 mm
Height51.7 mm
Weight350 g
