ATEN HDMI Over Cat5e/6 Audio/Video Extender (60m)
ATEN HDMI Over Cat5e/6 Audio/Video Extender (60m), 1920 x 1080 pixels, AV receiver, 3 m, Wired, Black, HDCP
Availability:: In stock
The VE800A HDMI Extender extends your HDMI display up to 60 m away from your HDMI source using one Cat 5e cable. ATEN's VE800A incorporates new technology that allows the A/V signals to be transmitted over a single Cat 5e cable. DDC port is provided for the ability to use the display's EDID by simply connecting another Cat 5e cable. The VE800A supports HDMI features such as 3D and Deep Color to give you the picture perfect viewing experience you desire.1x VE800AT HDMI Extender1x VE800AR HDMI Extender2x 0AD6-1705-10EG Power Adapters1x Mounting Kit1x User Instructions
| Features | |
|---|---|
| Type | AV receiver |
| Maximum resolution | 1920 x 1080 pixels |
| Cable types supported | Cat5,Cat6,Cat6a |
| Maximum transfer distance | 3 m |
| LED indicators | Y |
| Bandwidth | 225 MHz |
| HDCP | Y |
| Material | Metal |
| Product colour | Black |
| Ports & interfaces | |
| Connectivity technology | Wired |
| Ethernet LAN | Y |
| RJ-45 input ports | 2 |
| RJ-45 output ports | 2 |
| HDMI in | 1 |
| Number of HDMI outputs | 1 |
| DC-in jack | Y |
| Operational conditions | |
| Operating temperature (T-T) | 0 - 50 °C |
| Storage temperature (T-T) | -20 - 60 °C |
| Operating relative humidity (H-H) | 0 - 80 % |
| Weight & dimensions | |
| Width | 55 mm |
| Depth | 90 mm |
| Height | 22 mm |
| Weight | 484 g |
| Packaging data | |
| Package width | 59 mm |
| Package depth | 239 mm |
| Package height | 160 mm |
| Package weight | 644 g |
| Packaging content | |
| AC adapter included | Y |
| Logistics data | |
| Master (outer) case width | 250 mm |
| Master (outer) case length | 325 mm |
| Master (outer) case height | 175 mm |
| Master (outer) case gross weight | 3520 g |
| Master (outer) case net weight | 2420 g |
| Products per master (outer) case | 5 pc(s) |
