ATEN True 4K HDMI Repeater with Audio Embedder and De-Embedder
ATEN True 4K HDMI Repeater with Audio Embedder and De-Embedder
€121,90

ATEN True 4K HDMI Repeater with Audio Embedder and De-Embedder, 4096 x 2160 pixels, AV repeater, 5 m, Wired, Black, HDCP

Availability:: Arriving soon
EAN:4710469341076Categories:AV Equipment

The VC882 is a True 4K HDMI Repeater with Audio Embedder and De-Embedder capable of embedding or de-embedding the HDMI audio signal, while supporting the HDMI signal transmission distance up to 5 meters with True 4K resolution. Apart from embedding a separate audio to an outgoing HDMI signal, the VC882 also allows audio extraction from the HDMI signal, and outputs the extracted signal through an alternative audio system.In terms of the audio aspect, the VC882 works with versatile pass-through of HDMI audio formats – LPCM2.0, Dolby Digital 2.0, Dolby Digital 5.1 and DTS Digital 5.1. The VC882 also supports ARC function which eliminates the need of bulky cable setups when connecting an AV receiver, or a home theater system to a TV. When it comes to the video aspect, the VC882 supports True 4K (4096 x 2160 @ 60Hz 4:4:4) in HDR10, HDR10+, Dolby Vision and Hybrid Log-Gamma (HLG) formats to provide staggeringly crisp images. It is HDCP 2.2-compliant for content protection. The compact enclosure design, True 4K signal transmission, and embedding / de-embedding capability have made the VC882 ideal for training and conference rooms, video production, and home theater installations.

Features
TypeAV repeater
Maximum resolution4096 x 2160 pixels
Maximum transfer distance5 m
Maximum refresh rate60 Hz
LED indicatorsPower
Supported graphics resolutions4096 x 2160
Bandwidth600 MHz
HDCPY
MaterialMetal
Firmware upgradeableY
Impedance100 Ω
HDCP version2.2
Product colourBlack
Ports & interfaces
Connectivity technologyWired
HDMI in1
Number of HDMI outputs1
HDMI version2.0
USB ports quantity1
USB connector typeMicro-USB
Digital audio coaxial in1
Digital audio coaxial out1
Audio input3-pin terminal
Audio output3-pin terminal
DC-in jackY
Power
External power adapterY
Operational conditions
Operating temperature (T-T)0 - 40 °C
Storage temperature (T-T)-20 - 60 °C
Operating relative humidity (H-H)0 - 80 %
Weight & dimensions
Width82.2 mm
Depth122.2 mm
Height25 mm
Weight240 g
Packaging data
Package width59 mm
Package depth239 mm
Package height160 mm
Package weight970 g
Packaging content
AC adapter includedY
ManualY
Technical details
Country of originTaiwan
Package volume2265.35 cm³
Logistics data
Master (outer) case width250 mm
Master (outer) case length325 mm
Master (outer) case height175 mm
Master (outer) case gross weight4620 g
Master (outer) case volume14158.42 cm³
Master (outer) case net weight3920 g
Products per master (outer) case5 pc(s)
