ATEN 4-Port USB 3.1 Gen1 Industrial Switch
€134,91
ATEN 4-Port USB 3.1 Gen1 Industrial Switch, 5 Gbit/s, Black, Metal, 0 - 50 °C, -20 - 60 °C, 0 - 80%
Availability: In Stock
The US3344I is a 4-port USB3.1 Gen1 Industrial Switch that enables 4 computers to share the use USB3.1 Gen1 devices, such as keyboard, mouse and other peripheral devices. The peripheral focus can be given to a computer manually by using pushbutton on the switch.1x 4x4 USB 3.1 Gen 1 Industrial Hub Switch2x LIN6-11C1-E11G USB 3.1 Gen 1 Type-B to Type-A Cable 1.2M2x LIN6-11C1-E12G USB 3.1 Gen 1 Type-B to Type-A Cable 1.8M1x Remote Port Selector1x Mounting Kit1x Terminal Block Adapter Set (an RS-422/RS-485 and a DC terminal block adapter)1x User Instructions
| Ports & interfaces | |
|---|---|
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity | 4 |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-B ports quantity | 4 |
| DC-in jack | Y |
| Performance | |
| Maximum data transfer rate | 5 Gbit/s |
| LED indicators | Y |
| Hot-Plug support | Y |
| Product colour | Black |
| Housing material | Metal |
| Operational conditions | |
| Operating temperature (T-T) | 0 - 50 °C |
| Storage temperature (T-T) | -20 - 60 °C |
| Operating relative humidity (H-H) | 0 - 80 % |
| Weight & dimensions | |
| Width | 80 mm |
| Depth | 200 mm |
| Height | 25 mm |
| Weight | 885 g |
| Packaging content | |
| Cables included | USB Type-A - USB Type-B |
| Quick start guide | Y |
| Packaging data | |
| Package depth | 239 mm |
| Package width | 59 mm |
| Package height | 160 mm |
| Package weight | 1040 g |
| Logistics data | |
| Products per master (outer) case | 5 pc(s) |
| Master (outer) case gross weight | 5090 g |
| Master (outer) case length | 325 mm |
| Master (outer) case width | 250 mm |
| Master (outer) case height | 175 mm |
| Master (outer) case net weight | 4425 g |
