Zyxel ES-108A V3 Unmanaged Fast Ethernet (10/100) Metallic
Zyxel ES-108A V3, Unmanaged, Fast Ethernet (10/100), Full duplex, Wall mountable
Availability: Arriving Soon
Connect Multiple Devices with High Speed and ReliabilityThe ZyXEL ES-108A v3, a eight port desktop switch with plug-and-play design, can easily connect devices including PCs, network storage devices and print servers to your home network. The ES-108A v3 offers advanced High Priority ports to boost performance and user experience for Internet surfing, online gaming, multimedia or any application you prefer with prioritized bandwidth.Compliant with the IEEE 802.3az Energy Efficient Ethernet standard, the ES-108A v3 provides power-saving benefits without compromising performance.Compact, sturdy design with wall-mount alternativeThe ZyXEL ES-108A v3 fits any working environment. The stylish, compact metal housing with wall-mount installation design provides more flexibility for wired home networks. The affordable, reliable series comes with eight ports to meet home network expansion needs.Optimal bandwidth for media traffics through high priority portsThe ZyXEL ES-108A v3 comes with three high priority ports. With the port-based QoS feature, the ES-108A v3 provides considerably enhanced download quality. Users can experience better performance for Internet surfing, online gaming and multimedia streaming through prioritized bandwidth settings. The ES-108A v3 features increased buffer memory to maintain smooth network transmission while the switch is handling heavy loads.Easy to connect multiple devicesThe ZyXEL ES-108A v3 is designed to boost your home network with better performance and efficiency. With the N-way auto-negotiation function, the ES-108A v3 connects to network devices with the highest possible speed and activates full-duplex mode automatically, while the store-and-forward service offers low latency and error-free packet delivery.
| Management features | |
|---|---|
| Switch type | Unmanaged |
| Quality of Service (QoS) support | Y |
| Ports & interfaces | |
| Basic switching RJ-45 Ethernet ports quantity | 8 |
| Basic switching RJ-45 Ethernet ports type | Fast Ethernet (10/100) |
| Power connector | DC-in jack |
| Network | |
| Networking standards | IEEE 802.3,IEEE 802.3az,IEEE 802.3x |
| 10G support | N |
| Full duplex | Y |
| Flow control support | Y |
| Auto MDI/MDI-X | Y |
| Auto-negotiation | Y |
| Cable length detection | Y |
| Data transmission | |
| Switching capacity | 1.6 Gbit/s |
| MAC address table | 1000 entries |
| Store-and-forward | Y |
| Security | |
| MAC address filtering | Y |
| Design | |
| Product colour | Metallic |
| Reset button | Y |
| LED indicators | Y |
| Wall mountable | Y |
| Performance | |
| Buffer size | 56 KB |
| Plug and Play | Y |
| Power | |
| AC input voltage | 100 - 240 V |
| AC input frequency | 50 - 60 Hz |
| Input voltage | 100 - 240 V |
| Output voltage | 5 V |
| Output current | 1 A |
| Power consumption (max) | 1.52 W |
| Operational conditions | |
| Operating temperature (T-T) | 0 - 50 °C |
| Storage temperature (T-T) | -40 - 70 °C |
| Operating relative humidity (H-H) | 10 - 90 % |
| Storage relative humidity (H-H) | 10 - 95 % |
| Weight & dimensions | |
| Width | 155 mm |
| Depth | 85 mm |
| Height | 26 mm |
| Weight | 304 g |
| Packaging content | |
| User guide | Y |
| Packaging data | |
| AC adapter included | Y |
| Package width | 161 mm |
| Package depth | 90 mm |
| Package height | 95 mm |
| Package weight | 477.5 g |
| Logistics data | |
| Harmonized System (HS) code | 85176990 |
