ATEN DisplayPort / HDMI / VGA Switch with HDBaseT Transmitter
ATEN DisplayPort / HDMI / VGA Switch with HDBaseT Transmitter, 4096 x 2160 pixels, AV transmitter, 100 m, Wired, Black, HDCP
Availability:: Arriving soon
The ATEN VE3912T is an HDBaseT transmitter that extends 4K DisplayPort, HDMI, or VGA video signals up to 100 m over a single Cat 6/6a or ATEN 2L-2910 Cat 6 cable. Featuring multiple video input formats and output resolutions up to 4K, it ensures a superior video quality for applications that require digital/analog sources conversion and extension.1x VE3912T DisplayPort / HDMI / VGA Switch with HDBaseT Transmitter1x RS-232 Terminal Block1x 0AD8-1F05-30M1 Power Adapter4x Foot Pads1x User Instructions
| Features | |
|---|---|
| Type | AV transmitter |
| Maximum resolution | 4096 x 2160 pixels |
| Maximum transfer distance | 100 m |
| Supported video modes | 1080p,2160p |
| Supported graphics resolutions | 1600 x 1200 (UXGA),1920 x 1080 (HD 1080),1920 x 1200 (WUXGA),4096 x 2160 |
| Bandwidth | 340 MHz |
| Power | 8.77 W |
| On/off switch | Y |
| HDCP | Y |
| Material | Metal |
| Control type | Buttons |
| Consumer Electronics Control (CEC) support | Y |
| Impedance | 100 Ω |
| HDCP version | 2.2 |
| Product colour | Black |
| Ports & interfaces | |
| Connectivity technology | Wired |
| Ethernet LAN | Y |
| RJ-45 input ports | 1 |
| VGA (D-Sub) input ports | 1 |
| HDMI in | 1 |
| Number of HDMI outputs | 1 |
| DisplayPorts in | 1 |
| RS-232 output ports | 1 |
| Video in | 1 x HDMI Type A |
| Video out | 1 x HDMI Type A |
| VGA (D-Sub) ports quantity | 2 |
| Audio input | 1 x HDMI Type A |
| AUX in | Y |
| DC-in jack | Y |
| Power | |
| Power consumption (max) | 8.77 W |
| External power adapter | Y |
| Operational conditions | |
| Operating temperature (T-T) | 0 - 40 °C |
| Storage temperature (T-T) | -20 - 60 °C |
| Operating relative humidity (H-H) | 0 - 80 % |
| Weight & dimensions | |
| Width | 147 mm |
| Depth | 173 mm |
| Height | 30 mm |
| Weight | 1040 g |
| Packaging data | |
| Package width | 62 mm |
| Package depth | 283 mm |
| Package height | 173 mm |
| Package weight | 1118 g |
| Packaging content | |
| AC adapter included | Y |
| Quick start guide | Y |
| Mounting brackets included | Y |
| Technical details | |
| Compliance certificates | RoHS |
| Logistics data | |
| Master (outer) case width | 300 mm |
| Master (outer) case length | 336 mm |
| Master (outer) case height | 194 mm |
| Master (outer) case gross weight | 5590 g |
| Master (outer) case net weight | 5200 g |
| Products per master (outer) case | 5 pc(s) |
