StarTech.com 1-Port Serial-to-IP Ethernet Device Server - RS232 - DIN Rail Mountable
(0 review)Add your review
€473,14

StarTech.com 1-Port Serial-to-IP Ethernet Device Server - RS232 - DIN Rail Mountable, 10/100Base-T(X), 100 - 240 V, 12 V, 1.2 A, Type H, AU, EU, UK, US

Availability: Arriving Soon
EAN:0065030857161Categories:NetworkingTags:

A cost-effective way to connect, configure, and manage a remote RS-232 serial device over an IP networkThis 1-Port Serial Device Server lets you remotely access and manage an RS232 serial device over a local area network (LAN), for a simple and cost-effective serial-over-IP control solution.For more control options, the device server is compatible with the free, StarTech.com Serial Device Application Software NETRSAPP. When coupled with the NETRS232, this handy application for iOS and Android lets you build a custom serial control interface that’s tailored to your specific application.Flexible power and mounting optionsFor installation flexibility across a variety of environments, you can power the device server using the provided 12V DC power adapter, or using the integrated 1030V DC terminal block.Plus, the device server is DIN rail mountable for out-of-the-way installations.Protects your investmentTo help ensure reliable performance and prevent possible damage, the serial device server offers 15KV ESD (Electrostatic Discharge) protection, so you can rest assured that the device server won’t become damaged due to externally generated ESD.Customizable and wide compatibilityThis highly-customizable device server is easy to configure to suit your application. For easy setup, Windows users can use the provided Virtual COM port software, or the versatile web-based interface.The RS232 device server supports Telnet (an operating system independent communication protocol), so it can be integrated into mixed OS environments (Windows, Mac, Linux). Plus, it supports VCOM, TCP Server/Client, UDP, HTTP, DHCP, ICMP(PING), Static IP, and ARP protocols.Download the application software and manage your serial devices with easeDownload the StarTech.com serial control software from the Apple App Store or the Google Play™ Store.The NETRS232 is backed by a StarTech.com 2-year warranty and free lifetime technical support.The StarTech.com Advantage

Technical details
Serial ports quantity1
Serial interface typeRS-232
Surge protection voltage15
Networking standardsIEEE 802.3,IEEE 802.3u
Baud rate230.4
Auto MDI/MDI-XY
Data bits5,6,7,8
Flow Control typeN,RTS/CTS
Parity bitEven,Mark,N,Odd,Space
Stop bits1,1.5,2
Remote managementY
Compliance certificatesRoHS
CertificationCE, FCC, TAA, PSE, REACH
Ports & interfaces
Ethernet LAN (RJ-45) ports1
Wi-FiN
Cabling technology10/100Base-T(X)
Power
Input voltage100 - 240
Output voltage12
Output current1.2
Power plug typeType H
Compatible power plug typesAU,EU,UK,US
Input current0.5
Protocols
Supported network protocolsVCOM, TCP Server, TCP Client, UDP, HTTP, DHCP, ICMP(PING), Static IP, ARP, Telnet
Indication
LED indicatorsActivity,Link,Power
Power LEDY
Link/Act LEDY
Software
Windows operating systems supportedWindows 10,Windows 10 Education,Windows 10 Education x64,Windows 10 Enterprise,Windows 10 Enterprise x64,Windows 10 Home,Windows 10 Home x64,Windows 10 IOT Core,Windows 10 Pro,Windows 10 Pro x64,Windows 10 x64,Windows 2000,Windows 2000 Professional,Windows 7,Windows 7 Enterprise,Windows 7 Enterprise x64,Windows 7 Home Basic,Windows 7 Home Basic x64,Windows 7 Home Premium,Windows 7 Home Premium x64,Windows 7 Professional,Windows 7 Professional x64,Windows 7 Starter,Windows 7 Starter x64,Windows 7 Ultimate,Windows 7 Ultimate x64,Windows 8,Windows 8 Enterprise,Windows 8 Enterprise x64,Windows 8 Pro,Windows 8 Pro x64,Windows 8 x64,Windows 8.1,Windows 8.1 Enterprise,Windows 8.1 Enterprise x64,Windows 8.1 Pro,Windows 8.1 Pro x64,Windows 8.1 x64,Windows Vista,Windows Vista Business,Windows Vista Business x64,Windows Vista Enterprise,Windows Vista Enterprise x64,Windows Vista Home Basic,Windows Vista Home Basic x64,Windows Vista Home Premium,Windows Vista Home Premium x64,Windows Vista Ultimate,Windows Vista Ultimate x64,Windows Vista x64,Windows XP,Windows XP Home,Windows XP Home x64,Windows XP Professional,Windows XP Professional x64
Linux operating systems supportedY
Server operating systems supportedWindows Server 2003,Windows Server 2008 R2,Windows Server 2012,Windows Server 2012 R2,Windows Server 2016
Weight & dimensions
Weight68
Dimensions (WxDxH)55 x 95 x 22
Package width159
Package depth175
Package height76
Package weight444
Operational conditions
Operating temperature (T-T)0 - 60
Storage temperature (T-T)-10 - 70
Operating relative humidity (H-H)0 - 90
Design
Product colourBlack
Housing materialPlastic
Packaging content
AC adapter includedY
Logistics data
Products per master (outer) case12
Master (outer) case length394
Master (outer) case width330
Master (outer) case height271
