Vertiv Avocent MPU4032DAC KVM switch Rack mounting Black
Vertiv Avocent MPU4032DAC KVM switch Rack mounting Black, 1680 x 1200 pixels, Ethernet LAN, Rack mounting, 40 W, 1U, Black
Availability: Arriving Soon
The Avocent MergePoint Unity appliance is the fourth generation KVM over IP appliance from Avocent. This appliance provides IT administrators a complete remote management solution to access and control servers, networking equipment and other devices found in data centers and branch offices. The MergePoint Unity switch enhances the in-band management typically done through the NIC of IT equipment by providing secure and remote out-of-band connections directly to the physical KVM, USB and serial ports. This unified approach enables IT administrators a faster method to diagnose, reconfigure or restore equipment to meet SLAs and minimize downtime.
| Ports & interfaces | |
|---|---|
| Number of computers controlled | 32 |
| Keyboard port type | USB |
| Mouse port type | USB |
| Video port type | VGA |
| Console ports | RJ–45,USB A,VGA (D-Sub) |
| Console USB ports quantity | 4 |
| Network | |
| Ethernet LAN | Y |
| Ethernet LAN (RJ-45) ports | 2 |
| Cabling technology | 10/100/1000Base-T(X) |
| Security algorithms | 128-bit SSL,AES,DES,FIPS 140-2 |
| Performance | |
| Maximum resolution | 1680 x 1200 |
| Maximum analog resolution | 1600 x 1200 |
| Video bandwidth | 60 |
| Number of users | 1 |
| Design | |
| Rack mounting | Y |
| Rack capacity | 1U |
| Product colour | Black |
| Housing material | Metal |
| Cascadable | Y |
| LED indicators | Y |
| Certification | UL, FCC, cUL, ICES-003, CE, VCCI, KCC, C-Tick, GOST |
| Power | |
| Power source | AC |
| Input voltage | 100 - 240 |
| AC input frequency | 50 - 60 |
| Power consumption (typical) | 40 |
| External power adapter | N |
| Operational conditions | |
| Operating temperature (T-T) | 0 - 50 |
| Storage temperature (T-T) | -20 - 70 |
| Operating relative humidity (H-H) | 20 - 80 |
| Storage relative humidity (H-H) | 5 - 95 |
| Weight & dimensions | |
| Width | 437 |
| Depth | 431.8 |
| Height | 340 |
| Weight | 3900 |
| Packaging content | |
| Quick installation guide | Y |
| Rack mount kit | Y |
| Other features | |
| Connectivity technology | Wired |
| Dimensions (WxDxH) | 170 x 133.8 x 17.2 |
| Ports quantity | 32 |
| Power requirements | 100 - 240 VAC |
| Logistics data | |
| Harmonized System (HS) code | 85176200 |
