Teltonika DAP140 | Access point | Wi-Fi 4, passive PoE, 2x RJ45 100Mb/s
Teltonika DAP140 | Access point | Wi-Fi 4, passive PoE, 2x RJ45 100Mb/s
Availability:: Arriving soon
Teltonika DAP140 - Wi-Fi Access Point 4 with Passive PoEExpand your wireless network with the Teltonika DAP140, a Wi-Fi 4 access point that provides stable connectivity and wide compatibility with network devices. Equipped with Passive PoE and two 100 Mbps RJ45 ports, it allows for easy installation and efficient management of network traffic. With its robust design and intuitive configuration, it will work well in a variety of environments.Stable wireless networkThe Teltonika DAP140 enables smooth data transmission with Wi-Fi 4 (IEEE 802.11b/g/n) support. It can support up to 50 simultaneous users, making it a great choice for offices, warehouses and other spaces requiring a strong Wi-Fi signal. Mesh (802.11s) support provides greater range and connection stability.Two RJ45 ports and Passive PoEThe device is equipped with two RJ45 100 Mbps LAN ports that allow wired connection of additional devices. Passive PoE support allows power to be supplied via an Ethernet cable, eliminating the need for an additional power supply. This solution allows for faster and more flexible installation.Advanced security featuresThe DAP140 supports modern security protocols, including WPA3-SAE, WPA-EAP, OWE, and MAC filtering, providing a high level of network protection. The ability to hide SSIDs and isolate clients allows for better access control. Management via WebUI and SNMP interface provides easy configuration and monitoring.Easy setup and managementThe device can be remotely managed and monitored via Teltonika RMS, providing full control over the network. Support for protocols such as SSH, MQTT and DHCP allows integration with various network systems. An intuitive user interface (WebUI) allows for quick configuration and customization.
2.4 GHzYes5 GHzNoAntenna typeExternalBuilt-in processorYesCabling technology10/100Base-T(X)Command-line interface (CLI)YesDepth68.6DHCP clientYesDHCP serverYesEthernet LAN (RJ-45) ports2Ethernet LAN data rates10,100,1000Fast roamingYesFlash memory128Height25Housing materialAluminiumInternal memory16International Protection (IP) codeIP30IPv4 & IPv6 featuresDual stack IPv4/IPv6LED indicatorsPowerMAC address filteringYesMaximum data transfer rate300Maximum data transfer rate (2.4 GHz)300Networking standardsIEEE 802.11b, IEEE 802.11e, IEEE 802.11g, IEEE 802.11k, IEEE 802.11n, IEEE 802.11r, IEEE 802.11s, IEEE 802.11v, IEEE 802.3, IEEE 802.3az, IEEE 802.3uOperating relative humidity (H-H)10 - 90Operating system installedRutOSOperating temperature (T-T)-40 - 75PlacementShelf, WallPower over Ethernet (PoE)YesPower over Ethernet (PoE) type supportedPassive PoEProcessor frequency580Product colourBlackQuantity per pack1Reset buttonYesRS-232 interfaceYesSecurity algorithmsOWE, WPA-EAP, WPA-PSK, WPA2-EAP, WPA2-PSK, WPA3-EAP, WPA3-SAEStorage relative humidity (H-H)-50 - 75Storage temperature (T-T)10 - 90Supported network protocolsTCP, UDP, IPv4, IPv6, NTP, DNS, HTTP, HTTPS, FTP, SMTP, SSL/TLS, ARP, VRRP, PPP, PPPoE, UPNP, SSH, DHCP, Telnet, SNMP, MQTT, Wake On Lan (WOL)Universal Plug and Play (UPnP)YesVPN supportOpenVPN, IPsec, GRE, PPTP, L2TP, Stunnel, DMVPN, SSTP, ZeroTier, WireGuard, Tinc, TailscaleWAN connectionEthernet (RJ-45)Web-based managementYesWeight150Width113.1
