ATEN CL5808N-ATA-GG rack console 48.3 cm (19") Black 1U
(0 review)Add your review
€1521,25

ATEN CL5808N-ATA-GG, 48.3 cm (19"), LCD, USB, PS/2, USB, PS/2, VGA, German

Availability: Arriving Soon
EAN:4710469343582Categories:Servers & StorageTags:aten, rack consoles, cl5808n, ata, gg, rack

- The CL5808 Slideaway™ Dual Rail LCD KVM Switch is a control unit that allows access to multiple computers from two PS/2 or USB KVM consoles. An extra console port is provided on the rear panel to manage the LCD KVM switch from an optional external consoles.- The CL5808 19" LED-backlit LCD monitor and keyboard/touch pad modules slide independently of each other. To maximize space in your data center, the keyboard/touch pad module slides back to "hide away" when not in use, while the thin profile LCD monitor rotates back - flush against the rack - allowing convenient monitoring of computer activity. Quickly and conveniently switch computer access with station and port selection pushbutton switches located on the keyboard module. Even when the keyboard module is in the retracted position you can still switch access with the Port Up/Port Down pushbuttons located on the monitor module.- The CL5808 supports both PS/2 and USB keyboards and mice for the connected computers, and the CL5808 supports USB peripheral devices to be used with the attached computers. A single CL5808 can control up to 8 computers. As many as 31 additional compatible KVM switches can be daisy chained together, so that up to 256 computers can all be controlled from a single keyboard, monitor, and mouse console.

Display
Display diagonal19
DisplayLCD
On Screen Display (OSD)Y
Technical details
Plug and PlayY
Product colourBlack
Hot-Plug supportY
Operating relative humidity (H-H)0 - 80
Maximum resolution1280 x 1024
Rack mountingY
Number of computers controlled512
LED indicatorsY
Push buttonY
Compliance certificatesRoHS
Rack capacity1U
Ports & interfaces
VGA (D-Sub) ports quantity17
Keyboard port typeUSB, PS/2
Mouse port typeUSB, PS/2
Video port typeVGA
Keyboard
Keyboard languageGerman
Keyboard layoutQWERTZ
Hot keysY
Power
Power consumption (typical)27.2
Input current1
Operational conditions
Operating temperature (T-T)0 - 50
Storage temperature (T-T)-20 - 60
System requirements
Windows operating systems supportedY
Mac operating systems supportedY
Linux operating systems supportedY
Weight & dimensions
Width480
Height44
Depth680.4
Weight14760
Packaging content
Cables includedAC,KVM
Quick installation guideY
ManualY
Rack mount kitY
