Seagate Constellation 1TBGB SATA, 7200rpm internal hard drive 1 TB 64 MB 3.5" Serial ATA
Seagate Constellation 1TBGB SATA, 7200rpm, 1 TB, 7200 RPM, 64 MB, 3.5", Serial ATA
Availability:: Arriving soon
Supersize your enterprise storageThe Seagate® Enterprise Capacity 3.5 HDD V.3 (formerly Constellation® ES.3) delivers the scalability that data centres need to reliably meet their demanding growth of unstructured data.- Highest-capacity enterprise drive, up to 4TB for maximum density server and storage solutions- Perfect for reliable, 24×7 bulk data storage- Predictable 7,200-rpm performance even in the most rugged multi-drive SAS or SATA environments- Best-in-class energy efficiency with low power and cooling requirements- Protect your data and ease data disposal costs and management with the SED FIPS 140-2 optionSupersize your storageThe Constellation ES.3, with the industry's highest capacities in a 3.5 inch HDD form factor, is the perfect foundation for building maximum density server and storage solutions. These capacity-optimised hard drives support up to152TB of storage per square foot for a great return-on-investment for your enterprise storage.Reliable bulk data storage for a 24x7 worldBuilding high capacity RAID storage solutions requires predictable and consistent performance. With the Constellation ES.3, we take it a step further and ensure that your data is stored reliably in multi-drive chassis solutions.Boost your storage capacities – and conserve powerStoring massive amounts of unstructured data is easy and smart with the Constellation ES.3. Designed with best-in-class energy efficiency, it uses a minimum power and cooling envelope to store up to 152TB per square foot.
| Features | |
|---|---|
| HDD capacity | 1000 GB |
| HDD speed | 7200 RPM |
| Storage drive buffer size | 64 MB |
| HDD size | 3.5 " |
| Interface | Serial ATA |
| Read seek time | 8.5 ms |
| Write seek time | 9.5 ms |
| Average latency | 4.16 ms |
| Mean time between failures (MTBF) | 1200000 h |
| Power | |
| Power consumption (typical) | 6.40 W |
| Power consumption (read) | 7.42 W |
| Power consumption (write) | 6.21 W |
| Power consumption (idle) | 4.42 W |
| Operating voltage | 5 / 12 V |
| Start-up current | 1.88 A |
| Operational conditions | |
| Operating temperature (T-T) | 5 - 55 °C |
| Storage temperature (T-T) | -40 - 70 °C |
| Operating vibration | 0.25 Gs G |
| Non-operating vibration | 4.9 Gs G |
| Operating shock | 70 G |
| Non-operating shock | 350 G |
| Weight & dimensions | |
| Width | 101.85 mm |
| Height | 26.10 mm |
| Depth | 147 mm |
| Weight | 610 g |
| Other features | |
| Sustained data rate | 150 MB/s |
| Acoustic pressure emissions | 2.7 dB |
| Internal | Y |
| Data transfer rate | 6 Gbit/s |
